Electronic Test

RJD Controls Model 3 Variac Voltage Timer Control 115VAC DC Ammeter Benchtop

RJD Controls

SKU:

26686

Availability:

Usually ships within 1–2 business days.

Weight:

7.00 LBS

Brand:

RJD Controls

Model:

Model 3

MPN:

Model 3

Type:

Variac Voltage & Timer Control

SKU:

26686

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold as-is for parts or repair; includes Time Ranger timer module

Form Factor:

Benchtop

Power Requirements:

115VAC

Input Voltage:

115VAC

Output Connector:

DB9 (9-pin D-sub)

Current Meter Range:

0–5 DC Amperes

Controls:

Voltage knob, Coil switch, Power switch, Push-to-start

Timer Module:

Time Ranger (integrated)

Indicators:

Power LED (green), Current meter

Country/Region of Manufacture:

United States

Condition Notes:

RJD Controls Model 3 Variac Voltage Timer Control sold AS-IS for parts or repair. Not tested or guaranteed functional. Cosmetically intact with normal wear. All visible components present. Contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Oxford XC-90-B ECG Calibrator 8-Pot 8uV 25uV 50uV 100uV 1mV Output For Parts

Oxford

SKU:

28668

Availability:

Usually ships within 1-2 business days.

Weight:

3.00 LBS

Brand:

Oxford

Model:

XC-90-B

MPN:

XC-90-B

Type:

ECG Calibrator / Patient Simulator

SKU:

28668

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold as-is for parts or repair; includes unit with rear D-sub connector

Form Factor:

Benchtop

Number of Output Channels:

8

Output Voltage Levels:

8uV, 25uV, 50uV, 100uV, 1mV ECG

Output Port Type:

Banana / safety connector and BNC

Rear Connector:

D-Sub (25-pin female)

Controls:

ON/OFF switch, output level selector, indifferent lead

Indicator:

Yellow LED power indicator

Application:

ECG / EKG machine calibration, cardiac equipment testing

Country/Region of Manufacture:

United Kingdom

Condition Notes:

Oxford XC-90-B ECG Calibrator sold as-is for parts or repair. Not tested or guaranteed functional. We do not warranty or refurbish medical equipment. Housing shows general wear; rear panel has chipping near D-sub connector. Photos available.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

DSC Links 1000 Cellular Alarm Transmitter SG Security Communications RJ31X

DSC

SKU:

29103

Availability:

Usually ships within 1–2 business days.

Weight:

5.00 LBS

Brand:

DSC / SG Security Communications

Model:

Links 1000

MPN:

F53CAN-74349-KX-N

Type:

Cellular Alarm Transmitter

FCC ID:

F53LINKS1

Plug Type:

RJ31X

REN:

0.0B

DOC/MDC:

160 182 168C

LN/IC:

10

Manufacturer:

SG Security Communications, A Division of Sur-Gard Security Systems Ltd.

Country/Region of Manufacture:

Canada

FCC Compliance:

FCC Parts 15 and 68

Enclosure Type:

Wall-Mount Metal Enclosure with Locking Latch

Antenna Connector:

BNC (top-mounted on enclosure)

Form Factor:

Wall Mount

Condition:

As-Is / For Parts or Not Working

SKU:

29103

Seller Notes:

Sold as-is. Includes main PCB assembly in wall-mount enclosure with BNC antenna port.

Condition Notes:

DSC Links 1000 Cellular Alarm Transmitter sold as-is for parts or repair. Not tested, no functionality guaranteed. Internal PCB and enclosure present. Typical wear from prior use. Please contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

HP Hewlett-Packard 2470A Amplifier Module Gain Zero Multiplier For Parts

HP

SKU:

29605

Availability:

Usually ships within 1-2 business days.

Weight:

5.00 LBS

Brand:

HP

Model:

2470A

MPN:

2470A

Type:

Amplifier Module / Plug-In

SKU:

29605

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold AS-IS for parts or repair. Not tested or guaranteed functional.

Country/Region of Manufacture:

United States

Form Factor:

Plug-In Module

Controls:

Gain, Zero, Multiplier (1, 10, 30, 100, 300, 1000)

Connector Type:

D-Sub (rear), BNC-style front jacks

Fuse Rating:

1/2 Amp

Compatible With:

HP / Hewlett-Packard plug-in instrument systems

Measurement Type:

Signal Amplification

Interface:

D-Sub connector, Line Voltage input (rear panel)

Condition Notes:

HP 2470A Amplifier Module in used condition. Shows normal wear, grime, and discoloration on panels. All controls and connectors intact and functional.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Eaton 380K11 Synthesized Signal Generator PM3601 AM Modulation For Parts

Eaton

SKU:

31105

Availability:

Usually ships within 1-2 business days.

Weight:

97.00 LBS

Brand:

Eaton

Model:

380K11

MPN:

380K11

Type:

Synthesized Signal Generator

SKU:

31105

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold as-is for parts or repair. Includes PM3601 AM Modulation Section.

Sub-Model / Section:

PM3601 AM Modulation Section

Part Number 2:

P3602 0E1

Form Factor:

Benchtop / Rackmount

Modulation Type:

AM (Amplitude Modulation)

Frequency Range:

Up to 1000 MHz (1 GHz) — per front panel label

RF Output:

RF Output connector present (type: BNC or N-type, per photos)

Output Level Range:

0 dBm to -10 dBm (per front panel markings)

Modulation Input:

MOD IN connector present on front panel

Internal Components:

Multi-board assembly with ribbon cable interconnects; CAUTION HIGH VOLTAGE section

Country/Region of Manufacture:

United States

Condition Notes:

Eaton 380K11 Synthesized Signal Generator sold AS-IS for parts or repair. Not fully functional, not tested, no functionality guaranteed. Includes PM3601 AM Modulation Section. Please view photos and contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

AMC Barkhausen Tester PCB 549637-003 Rev XA Custom Enclosure DB25 DB9

AMC

SKU:

31262

Availability:

Usually ships within 1–2 business days.

Weight:

14.00 LBS

Brand:

AMC

Model:

549637-003

MPN:

549637-003

Secondary Model:

Rev XA

SKU:

31262

Type:

Barkhausen Tester PCB / Test Instrument

Condition:

As-Is / For Parts or Not Working

Form Factor:

Custom Desktop Enclosure

PCB Revision:

Rev XA

Interface / Connectors:

DB25 (female), DB9 (female), IDC ribbon cable

Display:

4-digit red LED numeric display

Enclosure Type:

Custom aluminum/steel desktop enclosure with blue trim

Seller Notes:

Sold AS-IS for parts or repair. Includes enclosure, PCB, ribbon cable, DB25, DB9 connectors.

Country/Region of Manufacture:

United States

Condition Notes:

AMC Barkhausen Tester PCB 549637-003 Rev XA sold AS-IS for parts or repair. Not tested or guaranteed functional. Enclosure, PCB, ribbon cable, DB25 and DB9 connectors included as shown. Please view photos and contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Varian VZC6961D7W1 C-Band TWT Amplifier TWTA 5.9-6.4 GHz 65 dB Gain Rackmount

Varian

SKU:

31387

Availability:

Usually ships within 1-2 business days.

Weight:

48.00 LBS

Brand:

Varian

Model:

VZC6961D7W1

MPN:

VZC6961D7W1

Secondary Model:

VZC-6969B1

Type:

C-Band Traveling Wave Tube Amplifier (TWTA)

SKU:

31387

Frequency Range:

5.9–6.4 GHz

Gain:

65 dB

Tube Type:

Traveling Wave Tube (TWT)

Band:

C-Band

Form Factor:

Rackmount

Front Panel Controls:

POWER, HV ON switches; STATUS and FAULT LED indicators

Front Panel Meter:

Helix Current (DC Milliamperes, 0–15 mA)

Hours Meter Reading:

937 hours (as photographed)

RF Connectors:

RF Input and RF Output (waveguide/coax, rear panel)

RF Sample Port:

BNC-type RF Sample port on side panel

Control Interface:

D-Sub multi-pin connector (rear panel); Local/Remote switch

Internal TWT Part Number:

113798-03

Internal TWT Date Code:

8613

Internal TWT Revision:

Rev. D

Varian Code Ident:

59782

Asset Tag / Label:

GIF 21860 (side panel label)

Made In:

USA

Country/Region of Manufacture:

United States

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Does not power on. Sold as-is for parts or repair. ~937 hours on meter.

Condition Notes:

Varian VZC6961D7W1 C-Band TWT Amplifier does not power on. Sold as-is for parts or repair only — not tested, no functionality guaranteed. ~937 hours on meter. Chassis and internals appear complete per photos.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Keltec Florida CR683-75 C-Band TWT Amplifier Thomson-CSF TH3641 TWTA

Keltec Florida

SKU:

31565

Availability:

Usually ships within 1–2 business days.

Weight:

1.00 LBS

Brand:

Keltec Florida

Model:

CR683-75

MPN:

CR683-75

Secondary Model:

863000

Type:

Traveling Wave Tube Amplifier (TWTA)

TWT Tube Model:

Thomson-CSF TH3641

Frequency Range:

5850–6425 MHz (C-Band)

TWTA Drive Power:

+6.4 dBm

TWTA Output Power (rated):

48.75 dBm

Filament Elapsed Time:

829 hours (meter-read)

RF Input Connector:

J3 (front panel, SMA/coax type)

RF Output Connector:

J4 (front panel, SMA/coax type)

RF Output Monitor:

J5 (front panel)

Remote Connector:

J2 (multi-pin circular, front panel)

Power Input Connector:

J1 (multi-pin circular, front panel)

Front Panel Indicators:

Helix Current meter, High Temp Alarm, Thermal O/L, Helix Current, Summary Fault, Operate, Standby, Time Delay, Power On lamps

Front Panel Controls:

Operate, Standby, Power On switches; Reset/Standby; Prime Power Circuit Breaker; Gain Adjust

Elapsed Time Meter:

Filament hours counter (mechanical totalizer)

Cooling:

Rear-mounted fan

Form Factor:

Benchtop / Rackmount chassis

Manufacturer:

Keltec Florida, a Division of Amstar Technical Products Co. Inc.

Date Code:

8636 (week 36, 1986)

MFR Code:

09062 US

Part Number:

863000

Application:

C-Band satellite uplink, ground station TWTA

Condition:

As-Is / For Parts or Not Working

SKU:

31565

Country/Region of Manufacture:

United States

Seller Notes:

Powers on but produces no RF output. Sold as-is for parts or repair.

Condition Notes:

Keltec Florida CR683-75 C-Band TWTA powers on but has no RF output. Sold as-is for parts or repair only. TH3641 tube reads 829 filament hours. Not guaranteed functional. No returns on as-is items.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Opti-Quip 1605 Mercury Xenon Lamp Power Supply DC Watts Watt-Meter Benchtop

Opti Quip

SKU:

31669

Availability:

Usually ships within 1–2 business days.

Weight:

10.00 LBS

Brand:

Opti-Quip

Model:

1605

MPN:

1605

Type:

Mercury/Xenon Arc Lamp Power Supply

SKU:

31669

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold as-is for parts or repair. Powers on; no lamp ignition.

Country/Region of Manufacture:

United States

Form Factor:

Benchtop

Compatible Lamp Types:

Mercury, Xenon Arc Lamps

Wattage Range (Mercury):

50W, 100W, 200W

Wattage Range (Xenon):

75W, 100W, 150W

Meter Type:

DC Watts / Watt-Meter with Volts and Amps scales

Front Panel Controls:

Mercury/Xenon watt selector, Power Adjust, Watt-Meter knob

Safety Features:

Over Temp indicator, Safety Interlock

Hours Meter:

Yes — electromechanical hours counter on front panel

Rear Connectors:

Multi-pin circular connector, IEC AC inlet, DB9-style port

Application:

Microscope illumination, optical instruments, spectroscopy

Manufacturer Location:

Highland Mills, New York 10930

Condition Notes:

Opti-Quip 1605 Mercury/Xenon Lamp Power Supply sold AS-IS for parts/repair. Powers on; Watt-Meter needle responds to knob. No lamp ignition. Could not fully test; may be missing parts. No functionality guarantee.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

DC Voltmeter 0-3500V Moving Coil Panel Meter 1945 Vintage High Voltage w/ Base

Black

SKU:

32915

Availability:

Usually ships within 1-2 business days.

Weight:

4.00 LBS

Brand:

Unbranded

Model:

Moving Coil DC Voltmeter 0-3500V

MPN:

REP.10A/7784

Type:

DC Panel Voltmeter

SKU:

32915

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Meter movement is OK; resistor is not working. Sold as-is with mounting base.

Measurement Type:

DC Voltage

Voltage Range:

0-3500V DC

Meter Movement Type:

Moving Coil (D'Arsonval)

Scale Markings:

0, 1000, 2000, 3000, 3500

Year / Date Code:

1945

Serial Number Reference:

Visible on dial face (internal use only)

Form Factor:

Panel Mount with Mounting Base

Housing Color:

Black

Mount / Base:

Includes black cast mounting base with rubber feet

Country/Region of Manufacture:

United States

Condition Notes:

Vintage 0-3500V DC moving coil panel voltmeter sold as-is for parts or repair. Meter movement appears intact but the series resistor is not working. Not guaranteed functional. Please view photos and contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Scientific Solutions 943244 Rev B AD Analog Multiplexer Module For Parts

SKU:

33465

Availability:

Usually ships within 1-2 business days.

Weight:

4.00 LBS

Brand:

Scientific Solutions

Model:

943244

MPN:

943244

Secondary Model:

943244 Rev B

Type:

Analog Multiplexer Module (PCB)

SKU:

33465

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold as-is for parts or repair. Includes housing/enclosure with PCB.

Country/Region of Manufacture:

United States

Form Factor:

Enclosed Module / Desktop

Revision:

Rev B

PCB Label:

AD Analog Multiplexer, Component Side

Copyright Year:

1991

Connector Type:

50-Pin Female SCSI-Style / Centronics

Input Termination:

Screw Terminal Blocks

Key ICs:

Maxim MAX series ICs (multiple, exact P/Ns not fully legible)

Application:

Data Acquisition, Signal Multiplexing, Lab Instrumentation

Interface Type:

50-Pin Parallel (Centronics-style)

Condition Notes:

Scientific Solutions 943244 Rev B Analog Multiplexer sold as-is for parts or repair. Not tested, no functionality guaranteed. Enclosure and PCB appear intact. Please view photos and contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Philips PM3243 10 MHz Dual-Beam 2-Channel Storage Oscilloscope For Parts

Philips

SKU:

34774

Availability:

Usually ships within 1-2 business days.

Weight:

28.00 LBS

Brand:

Philips

Model:

PM3243

MPN:

PM 3243

NC Number:

9444 032 43001

Type:

Analog Storage Oscilloscope

SKU:

34774

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold as-is for parts or repair; includes unit with carry handle

Country/Region of Manufacture:

Netherlands

Form Factor:

Benchtop

Bandwidth:

10 MHz

Number of Channels:

2

Display Type:

Analog CRT with Storage

Beam Type:

Dual-Beam

Power Requirements:

100-240V AC, 50-400Hz, 30 VA

Input Voltage Range:

100-240V AC

Power Consumption:

30 VA

Frequency Range:

50-400 Hz (power input)

Features:

Storage mode, Save/Read/Write/Erase/Persist controls

Condition Notes:

Philips PM3243 10 MHz storage oscilloscope sold as-is for parts or repair. Not tested or guaranteed functional. Appears complete externally with carry handle. Good source of parts. View photos; contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Heath Schlumberger SM-105A SM-104A Solid State Counter TCXO BCD 120/240V

Heath Schlumberger

SKU:

34971

Availability:

Usually ships within 1-2 business days.

Weight:

5.00 LBS

Brand:

Heath Schlumberger

Model:

SM-105A

Secondary Model:

SM-104A

MPN:

SM-105A / SM-104A

SKU:

34971

Type:

Solid State Frequency / Event Counter

Condition:

As-Is / For Parts or Not Working

Time Base:

TCXO (Temperature-Compensated Crystal Oscillator)

Time Base Stability:

1 part in 10E6 per year (SM-104A)

Output Type:

5-digit TTL-compatible BCD

Power Requirements:

120/240 VAC, 50/60 Hz, 12W

Input:

80V Max (front BNC input)

Form Factor:

Benchtop

Rear Connector:

DB25 parallel output connector

Country/Region of Manufacture:

United States

Seller Notes:

Sold AS-IS for parts or repair. Power cord included.

Condition Notes:

Heath Schlumberger SM-105A/SM-104A Solid State Counter sold AS-IS for parts or repair. Not confirmed working; no functionality guaranteed. Good source of components. Please review photos and contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

STMicroelectronics P6KE6V8A TVS Transient Voltage Suppressor Diode DO-41 Qty 10

STMICROELECTRONICS

SKU:

35120

Availability:

Usually ships within 1–2 business days.

Weight:

0.95 LBS

Brand:

STMicroelectronics

Model:

P6KE6V8A

MPN:

P6KE6V8A

Type:

Transient Voltage Suppressor (TVS) Diode

SKU:

35120

Package Type:

DO-41

Peak Pulse Power:

600W at 1.0 ms

Clamping Voltage:

Starts clamping at 7V

Breakdown Voltage:

6.8V

Response Time:

5.0 ns

Polarity:

Bidirectional

Junction Type:

Glass passivated

Lead Diameter:

0.033 in (0.85 mm)

Lead Length:

1.1 in each

Body Dimensions:

0.25 in long x 0.13 in diameter

Quantity:

10

Application:

ESD protection, overvoltage suppression, surge clamping

Country/Region of Manufacture:

China

Condition:

Open Box – New components, out of original packaging

Seller Notes:

Lot of 10 P6KE6V8A TVS diodes, banded; open box, new old stock

Condition Notes:

STMicroelectronics P6KE6V8A TVS diodes, new old stock, out of original packaging. Unused/unsoldered. Leads show minor surface weathering from storage; solderability expected to be good. Sold as a lot of 10, banded.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Littelfuse 5KP22CA TVS Diode 5kW 22V Transient Voltage Suppressor Lot of 10

Littlefuse

SKU:

35121

Availability:

Usually ships within 1–2 business days.

Weight:

0.50 LBS

Brand:

Littelfuse

Model:

5KP22CA

MPN:

5KP22CA

Type:

TVS Diode – Transient Voltage Suppressor

SKU:

35121

Quantity:

10 pieces per lot

Peak Pulse Power:

5000W (5kW) at 1.0ms

Standoff Voltage (Vwm):

22V

Breakdown Voltage:

24.4V minimum

Clamping Voltage (Vc):

Starts clamping at 26.5V

Polarity:

Bidirectional (CA suffix)

Response Time:

5.0 ns

Package / Case:

DO-201 axial leaded

Package Dimensions:

0.28" long x 0.375" dia; leads 1.1" each

Lead Diameter:

0.042" (1.07mm)

Junction Type:

Glass passivated

Seller Notes:

Sold in a lot of 10 components. Minor surface weathering; solderability confirmed.

Country/Region of Manufacture:

China

Application:

ESD protection, surge suppression, transient clamping

Condition:

New

Condition Notes:

New Littelfuse 5KP22CA TVS diodes. Minor surface weathering from storage — cosmetic only, solderability unaffected. Lot of 10 on tape carrier. Please view our photos and contact us with any questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Fairchild MMBT2222AR-R PNP SOT-23 Transistor R2T SMD 40V 0.5A Qty 10 TSOT23

Fairchild

SKU:

35122

Availability:

Usually ships within 1–2 business days.

Weight:

1.00 LBS

Brand:

Fairchild

Model:

MMBT2222AR-R

MPN:

MMBT2222AR-R

Secondary Model:

TSOT23-2222A

SKU:

35122

Type:

PNP Bipolar Junction Transistor (BJT)

Package / Case:

SOT-23 (3-pin SMD)

Transistor Polarity:

PNP

Device Marking:

R2T

Voltage - Collector Emitter Breakdown (Max):

~40V

Current - Collector (Ic) (Max):

~0.5A

Mounting Type:

Surface Mount (SMD/SMT)

Quantity:

10 pieces (on tape)

Complementary Device:

2N2222A / MMBT2222A (NPN)

Pin Configuration:

Base lower-left, Emitter right, Collector top (R2T up)

Seller Notes:

Sold as a pack of 10 on tape. New old stock.

Country/Region of Manufacture:

Philippines

Form Factor:

SMD / Surface Mount

Condition Notes:

Fairchild MMBT2222AR-R PNP SOT-23 transistors, new old stock, pack of 10 on tape. Unused, new condition. Please contact us with any questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

ON Semiconductor DF08S Bridge Rectifier 800V 1.5A 1.1V Vf SMD SMA Qty 10

ON Semiconductor

SKU:

35129

Availability:

Usually ships within 1-2 business days.

Weight:

0.50 LBS

Brand:

ON Semiconductor

Model:

DF08S

MPN:

DF08S

Type:

Bridge Rectifier

SKU:

35129

Quantity:

10 (sold as a set in tape strip)

Package / Case:

SMA (SMD Surface Mount)

Peak Reverse Voltage (PRV):

800 V

Forward Current (If):

1.5 A

Forward Voltage (Vf) Max:

1.1 V

Max Surge Current (IFSM):

50 A

Mount Type:

Surface Mount (SMD)

Configuration:

Single-Phase Full-Wave Bridge

Country/Region of Manufacture:

China

Seller Notes:

Set of 10 units, supplied in tape strip as photographed

Condition:

New

Condition Notes:

ON Semiconductor DF08S Bridge Rectifiers are new and unused, supplied in a tape strip of 10 units. Original manufacturer packaging may not be included. Please view photos and contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Wegener Communications 1601-54 Rev A Series 1600 Mainframe 19" Rackmount 3U RF

Wegener Communications

SKU:

35186

Availability:

Usually ships within 1-2 business days.

Weight:

20.00 LBS

Brand:

Wegener Communications

Model:

1601-54

MPN:

1601-54

Secondary Model:

Rev A

Type:

Rackmount Card Mainframe / Plug-In Card Shelf

SKU:

35186

Series:

Series 1600

Compatible With:

Wegener Series 1600 and Series 1700 plug-in cards

Form Factor:

19" Rack Mount, 3U

Number of Card Slots:

6 plug-in card slots

Includes:

Power supply module + six plug-in cards (functions unknown)

Power Requirements:

AC mains via IEC inlet; fuse: 1 AMP (F1)

Power Switch:

ON/OFF toggle switch on rear backplane

Backplane Connectors:

Multiple card-edge and ribbon/IDC connectors on backplane

Application:

Satellite communications / broadcast RF signal processing

Condition:

As-Is / For Parts or Not Working

Country/Region of Manufacture:

United States

Seller Notes:

Includes power supply and six plug-in cards; functions of cards unknown

Condition Notes:

Wegener 1601-54 Rev A Series 1600 Mainframe powers on and lights up but cannot be fully tested. Sold as-is for parts or repair. Includes power supply and six plug-in cards of unknown function. No functionality guarantee.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Varian VZC-6965 Cable Set Amplifier to Power Supply NEMA L5-30 125V 30A

Varian

SKU:

35902

Availability:

Usually ships within 1-2 business days.

Weight:

5.00 LBS

Brand:

Varian

Model:

VZC-6965

MPN:

00-112820-07 N

Type:

Amplifier to Power Supply Cable Set

SKU:

35902

Condition:

Used – Inspected and Tested

Compatible With:

Varian VZC-6965 TWT Amplifier

Connector Type 1:

NEMA L5-30 (125V, 30A, twist-lock)

Connector Type 2:

Military-style circular connector

Connector Type 3:

D-Sub (DB-15 and DB-9 style)

Cable Jacket:

10/3 Type SO, 90°C, R-123-70-MSHA rated

Power Rating:

125V, 30A

Harness Part Number:

00-112820-07 N

Seller Notes:

Includes power cable (NEMA L5-30) and multi-conductor signal harness assembly.

Application:

TWT / TWTA Satellite Communications Amplifier

Condition Notes:

Varian VZC-6965 Amplifier to Power Supply Cable Set. Tested and in good working condition. Includes NEMA L5-30 power cable (125V/30A) and signal harness P/N 00-112820-07 N. Normal wear. Please contact us with questions.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov

Allen Avionics Highpass Filter 300 kHz 50 Ohm SMA RF Signal For Parts

Allen Avionics Inc.

SKU:

35908

Availability:

Usually ships within 1–2 business days.

Weight:

1.00 LBS

Brand:

Allen Avionics

Model:

Highpass Filter 300 kHz

MPN:

No P/N

Type:

Highpass Filter

SKU:

35908

Condition:

As-Is / For Parts or Not Working

Seller Notes:

Sold as-is for parts or repair. No functionality guarantee.

Country/Region of Manufacture:

United States

Cutoff Frequency:

300 kHz

Impedance:

50 Ohms

Connector Type:

SMA (Female)

Filter Type:

Highpass

Housing / Enclosure:

Shielded metal box, painted gray

Manufacturer Location:

Mineola, NY 11501

Form Factor:

Inline / Benchtop Module

Condition Notes:

Allen Avionics Highpass Filter 300 kHz 50 Ohm SMA RF. Used condition, intact housing with light wear, both SMA connectors undamaged and functional.

California Prop 65 Warning:

WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov
