Leon L3-1K Subwoofer Amplifier 1000W Class A/B Dual Ch Rackmount 100-240V

Leon

SKU:

52998

Availability:

Usually ships within 1-2 business days.

Weight:

30.00 LBS

Brand:

Leon

Model:

L3-1K

MPN:

L3-1K

Type:

Subwoofer Amplifier

SKU:

52998

Condition:

As-Is / For Parts or Not Working

Power Output:

1000W

Amplifier Class:

Class A/B

Number of Channels:

2

Line Voltage:

100-120VAC / 200-240VAC switchable

AC Mains Fuse (120V):

T10AL

AC Mains Fuse (230V):

T5AL

Frequency:

50/60Hz

Standby Power (120V):

24W

Standby Power (230V):

18.4W

Crossover Frequency Range:

30-200Hz (with bypass)

Bass Boost:

-3 dB @ 25 Hz, Q = 1.4

High Pass Filter:

-3 dB @ 80 Hz, 12 dB/octave

Minimum Speaker Impedance:

4 Ohms combined load

Input Connectors:

RCA (L/R, LFE); 3.5mm 12V trigger

Output Connectors:

Binding post speaker outputs; RCA High Pass output

Remote Turn On:

Manual, Auto, or 12V Trigger

Subsonic Filter:

Switchable

Bass Boost Filter:

Switchable

EQ:

Low frequency parametric EQ (Freq, Bandwidth, Level controls)

Form Factor:

Rackmount, 2U

Rack Mount Brackets:

Included

Country/Region of Manufacture:

China

Certifications:

UL Listed (E205670), CE

Seller Notes:

Sold AS-IS. Powers on; High Pass output functional. Other audio outputs not working.

Condition Notes:

This Leon L3-1K 1000W Dual Channel Subwoofer Amplifier is being sold AS-IS for parts or repair. The unit does power on, and we have tested it to produce audio output through the High Pass output; however, the remaining audio outputs are not
