GNP PDSi 3U cPSB 8+1 Switch Module 1-503251 Rev A cPCI Backplane Card

(No reviews yet) Write a Review
SKU:
24414
MPN:
1-503251
Condition:
Used
Availability:
Usually ships within 1-2 business days.
Weight:
5.00 LBS
Shipping:
Calculated at Checkout
  • GNP PDSi 3U cPSB 8+1 Switch 1-503251 – two PCB modules and front panel bracket, top view
  • GNP PDSi 3U cPSB 8+1 Switch 1-503251 Rev A – single module angled view showing Kendin K38999 controller chip and edge connector
  • GNP PDSi 3U cPSB 8+1 Switch PCB label closeup showing '3U cPSB 8+1 Switch', 'Made in USA', PCB# 1-503251 REV. A, and 3.3V marking
$35.00
Was: $70.00
Current Stock: 20

Sold Out

Description

GNP PDSi 3U cPSB 8+1 Switch Module 1-503251 Rev A cPCI Backplane Card

A 3U CompactPCI switch module designed for cPSB (CompactPCI Switched Backplane) systems. This 8+1 configuration provides switching connectivity for CompactPCI chassis and distributed computing environments.

Specifications & What's Included

  • Model: GNP PDSi 1-503251 Rev A
  • Form Factor: 3U CompactPCI (cPCI) Card/Module
  • Switch Configuration: 8+1
  • Bus Interface: CompactPCI (cPCI) / cPSB
  • Manufactured: United States
  • Contents: Two PCBs and one front panel bracket

Applications

Switch modules of this type were used in CompactPCI-based telecommunications, industrial control, and data acquisition systems requiring switched backplane connectivity. Compatible with 3U CompactPCI/cPSB chassis systems commonly deployed in telecom infrastructure, military, and embedded computing platforms from the 2000s–2010s era.

Condition: Used
This GNP PDSi 3U cPSB 8+1 Switch module (PCB# 1-503251 Rev A) has been inspected and is in good used condition. The boards appear clean with no visible damage to the PCB traces, connectors, or components. The photos show two PCB modules and a front panel bracket; please review our photo set for the exact contents of this listing. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
View AllClose

Warranty Information

We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose

Additional Information

Brand:
GNP PDSi
Model:
1-503251
MPN:
1-503251
Secondary Model:
PCB# 1-503251 REV. A
Type:
3U CompactPCI cPSB 8+1 Switch Module
SKU:
24414
Form Factor:
3U CompactPCI (cPCI) Card/Module
Hardware Revision:
Rev A
Bus Interface:
CompactPCI (cPCI) / cPSB
Switch Configuration:
8+1
Country/Region of Manufacture:
United States
Condition:
Used – Inspected and in Good Condition
Seller Notes:
Two PCBs and one front panel bracket visible in photos; qty may vary
Compatible With:
CompactPCI / cPSB 3U chassis systems
Condition Notes:
GNP PDSi 3U cPSB 8+1 Switch 1-503251 Rev A. Inspected and in good used condition. Boards appear clean with no visible damage. See photos for exact contents.
View AllClose

Related Products

Related Products

GNP PDSi 1-503751 3U cPSB 8FE+2GE Switch Module — front panel view showing RJ-45 ports, LED indicators, and power LED GNP PDSi 1-503751 Ethernet Switch Module — rear/board view showing PCB components, ICs, and CompactPCI edge connector
Add to Cart
Quick view

GNP PDSi 1-503751 Rev C 3U cPCI cPSB 8FE 2GE Ethernet Switch Module

GNP

$95.00
Was: $200.00
GNP PDSi 1-503751 Rev C 3U cPCI cPSB 8FE 2GE Ethernet Switch ModuleManaged Ethernet switch module for 3U CompactPCI systems. This PCB provides network connectivity with 8 Fast Ethernet ports and 2...
24415
SKU:
24415
Availability:
Usually ships within 1-2 business days.
Weight:
4.00 LBS
Brand:
GNP PDSi
Model:
1-503751
MPN:
1-503751
PCB Revision:
Rev C
Type:
Embedded Ethernet Switch Module
SKU:
24415
Form Factor:
3U CompactPCI / cPSB
Number of Ports:
10 (8x Fast Ethernet + 2x Gigabit Ethernet)
Fast Ethernet Ports:
8
Gigabit Ethernet Ports:
2
Port Speed:
10/100 Mbps (FE), 1 Gbps (GE)
Bus Interface:
cPSB / CompactPCI
Management Type:
Managed
Interface Type:
Ethernet, Fast Ethernet, Gigabit Ethernet
Connector Type:
RJ-45, CompactPCI backplane
Condition:
Used – Inspected and in Good Condition
Seller Notes:
PCB only — no chassis or accessories included
Compatible With:
3U cPSB / CompactPCI chassis and backplanes
Condition Notes:
GNP PDSi 1-503751 Rev C 3U cPSB 8FE+2GE Switch Module. Inspected and in good used condition. Normal light wear from prior installation. Ports and edge connector appear intact and undamaged.
GNP PDSi 1-503252CN 3U cPCI cPSB 8+1 Switch Card – angled top view showing Kendin controller IC, memory chips, and J1/J2 CompactPCI edge connectors GNP PDSi 1-503252CN CompactPCI Switch Card – side-angle view showing full board layout with Kendin IC, header pins, and cPCI edge connector detail
Add to Cart
Quick view

GNP PDSi 1-503252CN 3U cPCI cPSB 8+1 Switch Card CompactPCI J1 J2 Bus

GNP

$40.00
Was: $125.00
GNP PDSi 1-503252CN 3U cPCI cPSB 8+1 Switch Card CompactPCI J1 J2 BusA 3U CompactPCI bus switch card with 8+1 switching configuration. This card routes and manages data traffic across CompactPCI...
24330
SKU:
24330
Availability:
Usually ships within 1–2 business days.
Weight:
3.00 LBS
Brand:
GNP PDSi
Model:
1-503252CN
MPN:
1-503252CN
Type:
CompactPCI cPSB 8+1 Bus Switch Card
SKU:
24330
Bus Standard:
CompactPCI (cPCI) / cPSB
Form Factor:
3U CompactPCI Card/Module
Switch Configuration:
8+1
Connector Type:
J1 and J2 CompactPCI Bus Connectors
Main Controller Chip:
Kendin (large QFP IC, part number partially legible)
Condition:
Used – Inspected
Seller Notes:
Card only; no additional accessories included.
Country/Region of Manufacture:
United States
Condition Notes:
GNP PDSi 1-503252CN 3U cPCI cPSB 8+1 Switch Card. Inspected, in good used condition. Board is clean; J1/J2 connectors intact. Pulled from a working environment.
GNP 1-503285 AM 3U cPSB 8+1 RTM cPCI Switch Board — front view showing four RJ-45 ports (Port 1, Port 2, Port 3, MGT Port) and ejector handle GNP 1-503285 AM cPCI Switch Board — rear/top view showing J2 connector, GNP label, board traces, and RJ-45 port array
