Accuvision 200 SECS II Receiver J1 Card 0001-0003-01 Rev B w/ Digital I/O Cable
This listing is for an Accuvision 200 SECS II Receiver J1 interface card (part number 0001-0003-01, Revision B) together with its Digital I/O Cable assembly (part number 0001-00219-00, DB-50S connector). The card provides the SECS II communications interface for the Accuvision 200 semiconductor process control platform, handling the J1 receiver channel and associated digital I/O signaling between the host controller and connected process equipment.
Specifications & What's Included
- Manufacturer: Accuvision
- Compatible System: Accuvision 200 semiconductor process control system
- Card Part Number: 0001-0003-01 (also printed on PCB as 0001-00003-01)
- Revision: Rev B
- PCB Copyright Date: 1993
- Function: SECS II Receiver, J1 channel, Digital I/O
- Interface Standard: SECS II (SEMI Equipment Communications Standard II)
- Form Factor: PCB card / module
- Notable ICs: GAL16V8B 25LP programmable logic device (visible at U18/U24 area)
- Included Cable: Digital I/O Cable Assembly, p/n 0001-00219-00
- Cable Connector: DB-50S (labeled on cable assembly tag)
- Country of Manufacture: USA (per PCB silkscreen)
Applications
SECS II (SEMI Equipment Communications Standard II) is the semiconductor industry's long-established protocol for communication between host computer systems and wafer fabrication equipment such as diffusion furnaces, CVD systems, etch tools, and ion implanters. Standardized by SEMI in the 1980s, SECS II defines the message structure that travels over the physical SECS-I serial link (or later HSMS TCP/IP), allowing fab-wide automation software to send recipes, collect process data, and manage equipment state. The Accuvision 200 was a process control and data acquisition platform used in semiconductor wafer fabs during the late 1980s and early 1990s, a period when centralized host-to-equipment communication via SECS was becoming standard practice. The J1 Receiver card handles the incoming SECS II signal on the designated J1 channel, with the Digital I/O cable carrying the discrete control and status signals between the card and the connected process tool. Today these cards are sought by facilities that continue to operate legacy Accuvision 200 systems, or by engineers maintaining or reverse-engineering older SECS II-based fab automation setups.
This Accuvision 200 SECS II Receiver J1 Card (p/n 0001-0003-01, Rev B) has been inspected and appears to be in good used condition. The PCB shows normal light handling wear consistent with prior lab or fab use; no visible damage, broken components, or missing parts are noted. The included Digital I/O Cable assembly (p/n 0001-00219-00, DB-50S connector) is also present and shows typical light wear. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Accuvision |
Model: |
200 |
MPN: |
0001-0003-01 |
Secondary Model: |
0001-00219-00 |
Type: |
SECS II Receiver Interface Card with Digital I/O Cable |
SKU: |
29876 |
Revision: |
Rev B |
Interface Standard: |
SECS II (SEMI Equipment Communications Standard) |
Connector Type: |
DB-50S |
Form Factor: |
Card / PCB Module |
Application: |
Semiconductor wafer fab equipment communication |
Included Accessories: |
Digital I/O Cable, SECS II Receiver J1, p/n 0001-00219-00 |
Compatible With: |
Accuvision 200 semiconductor process control system |
Country/Region of Manufacture: |
United States |
Condition: |
Used – Inspected, appears in good condition |
Seller Notes: |
Includes Digital I/O Cable assembly (p/n 0001-00219-00, DB-50S) |
Condition Notes: |
Accuvision 200 SECS II Receiver J1 Card (0001-0003-01 Rev B) inspected, appears in good used condition. Includes Digital I/O Cable (0001-00219-00, DB-50S). Normal light wear. Please contact us with questions. |
