Volkmann M-8010AB High Voltage Heat Sink Assy Fuji EVL31-050 GE Capacitors 500V
Chassis-mounted heat sink assembly from a Volkmann adjustable frequency AC drive. Contains Fuji transistor modules, GE capacitors, Dale resistors, and a 220VAC cooling fan.
Specifications & What's Included
- Three Fuji Electric EVL31-050 transistor modules (100A, 500V each)
- Two GE capacitors, 1.0 µF, 1000 VPK
- Two Dale resistors, 0.1 Ohm, 25W
- 220VAC fan, 16W, 4.5" diameter
- Overall dimensions: 15" x 7.5" x 6.5"
- Heat sink fins: 12" x 4.5" x 4.5"
- Voltage rating: 500V (transistor modules), 1000 VPK (capacitors)
Applications
Designed for use in Volkmann 70545AA (30 KVA) or 70490AA (40 KVA) adjustable frequency AC drives operating at 0–667 Hz output frequency.
Condition: Used
This Volkmann M-8010AB high voltage heat sink assembly has been visually inspected and shows typical cosmetic wear consistent with prior industrial use. It was removed from a Volkmann 30/40 KVA adjustable frequency AC drive. It has not been bench-tested at our facility and is sold without a functionality guarantee. Please view our photos and reach out with any questions before purchasing. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
This Volkmann M-8010AB high voltage heat sink assembly has been visually inspected and shows typical cosmetic wear consistent with prior industrial use. It was removed from a Volkmann 30/40 KVA adjustable frequency AC drive. It has not been bench-tested at our facility and is sold without a functionality guarantee. Please view our photos and reach out with any questions before purchasing. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Volkmann |
Model: |
M-8010AB |
MPN: |
M-8010AB |
SKU: |
48454 |
Condition: |
Used – Inspected |
Seller Notes: |
Includes mounted Fuji transistor modules, GE capacitors, Dale resistors, and 220VAC fan |
Form Factor: |
Chassis-mounted assembly |
Compatible With: |
Volkmann 70545AA 30 KVA Adjustable Frequency AC Drive |
Compatible With 2: |
Volkmann 70490AA 40 KVA Adjustable Frequency AC Drive |
Overall Dimensions: |
15" x 7.5" x 6.5" |
Heat Sink Fin Dimensions: |
12" x 4.5" x 4.5" |
Voltage Rating: |
500 V (transistor modules); 1000 VPK (capacitors) |
Current Rating: |
100 A per transistor module |
Power Requirements (Fan): |
220 VAC, 16 W, 4.5" diameter |
Transistor Module: |
Fuji Electric EVL31-050, 100A, 500V (QTY 3) |
Capacitor Part Number: |
GE 26F6769FC, 1.0 uF, 1000 VPK, 10 KHz (QTY 2) |
Resistor Part Number: |
Dale HL-25-06Z, 0.1 Ohm, 25 W (QTY 2) |
Frequency Range: |
0–667 Hz (parent drive output) |
Parent System: |
Volkmann 70545AA / 70490AA 30/40 KVA Adjustable Frequency Drive |
Country of Manufacture: |
USA |
