Silicon Quest 4in 100mm N-Type Polished Silicon Wafers 525±25µm 320-480Ω·cm Qty

(No reviews yet) Write a Review
SKU:
53135
MPN:
4in
Condition:
Used
Availability:
Usually ships within 1–2 business days.
Weight:
8.00 LBS
Shipping:
Calculated at Checkout
  • Silicon Quest International 4-inch polished silicon wafers in multiple clear plastic wafer carrier trays with one individual wafer displayed in foreground
  • Three Silicon Quest International wafer carriers open showing wafers loaded in slots with green ACCEPT inspection labels visible on packaging
  • Silicon Quest International wafer carrier label showing Part 03-08-007, Lot 4N0320-480PRM/FZ, 4-inch diameter, N/PHOS dopant, 320-480 Ohm-cm resistivity, 525±25µm thickness, <1-0-0> orientation, ACCEPT stamp
  • Close-up of multiple 4-inch polished silicon wafers standing vertically in carrier tray showing mirror-polished surfaces
  • Silicon Quest International wafer carrier label closeup showing Part 03-08-007, SEMICOA customer, 4N0320-480PRM/FZ lot, ACCEPT inspection stamp, DSP 1 Flat 80/50 Surface designation
  • Side view of approximately ten 4-inch polished silicon wafers standing in clear plastic wafer carrier showing wafer thickness and polished edges
  • Silicon Quest International wafer carrier label showing Part 03-08-007, quantity 5 noted on green sticker, 4N0320-480PRM/FZ lot, 320-480 Ohm-cm resistivity, ACCEPT inspection stamp
  • Side view of approximately five 4-inch polished silicon wafers in clear plastic wafer carrier showing dark mirror-polished surfaces
  • Three closed clear plastic wafer carrier trays with Silicon Quest International labels and green ACCEPT inspection stickers, stacked together
$550.00
Was: $1,100.00
Current Stock: 1

Sold Out

Description

Silicon Quest 4in 100mm N-Type Polished Silicon Wafers 525±25µm 320-480Ω·cm Qty 50

This lot consists of 50 Silicon Quest International (SQI) 4-inch (100mm) single-side polished N-Type silicon wafers, Part Number 03-08-007, Lot 4N0320-480PRM/FZ. The wafers are phosphorus-doped (N/PHOS) with a <1-0-0> crystal orientation and carry a DSP 1 Flat, 80/50 surface designation. All 50 wafers are stored in their original clear plastic wafer carrier trays with carrier labels and vendor ACCEPT quality-control inspection stamps intact.

Specifications & What's Included

  • Manufacturer: Silicon Quest International (SQI)
  • Part Number: 03-08-007
  • Lot Number: 4N0320-480PRM/FZ
  • Quantity: 50 polished silicon wafers
  • Diameter: 4 inches (100 mm)
  • Thickness: 525 ± 25 µm
  • Resistivity: 320 – 480 Ω·cm
  • Dopant / Type: N-Type / Phosphorus (N/PHOS)
  • Crystal Orientation: <1-0-0>
  • Surface: DSP 1 Flat, 80/50 Surface finish
  • Storage: Three original clear plastic wafer carrier trays with labeled lids and ACCEPT QC inspection stamps

Applications

Four-inch (100mm) N-Type polished silicon wafers are a standard substrate used in semiconductor device fabrication, microelectromechanical systems (MEMS) research, photolithography process development, thin-film deposition, and epitaxial layer growth. The <1-0-0> orientation is widely specified for CMOS and bipolar process flows, and the 320–480 Ω·cm resistivity range suits applications requiring moderately high-resistivity substrates, such as power device research, RF applications, and certain MEMS structures. Silicon Quest International was a well-regarded supplier of prime and research-grade silicon wafers for semiconductor foundries, university research labs, and government research programs. The 4-inch wafer format was the dominant fab standard from the mid-1970s through the 1980s and remained in active use in legacy fabs and research environments through the 2000s and beyond; it continues to be used today in MEMS foundries, university labs, and specialized low-volume production lines that have not transitioned to 200mm or 300mm tooling.

Condition: Used
These Silicon Quest International 4-inch N-Type polished silicon wafers have been inspected and appear to be in good condition. The wafers were pulled from a working semiconductor environment and remain stored in their original clear plastic carrier trays with carrier labels intact. The wafer surfaces appear clean and unscratched in our photos, consistent with proper storage in the wafer carriers. Carrier labels are present on each tray and show the full lot specification (Part 03-08-007, Lot 4N0320-480PRM/FZ), along with ACCEPT inspection stamps from the original vendor quality control process. Please view our photo set and contact us if you have any questions.
View AllClose

Warranty Information

We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose

Additional Information

Brand:
Silicon Quest International
Model:
03-08-007
MPN:
03-08-007
Type:
Polished Silicon Wafer
SKU:
53135
Quantity:
50 wafers
Diameter:
4 inches (100mm)
Thickness:
525 ± 25 µm
Resistivity:
320 – 480 Ω·cm
Dopant / Type:
N-Type / Phosphorus (N/PHOS)
Orientation:
<1-0-0>
Surface:
DSP 1 Flat, 80/50 Surface
Lot Number:
4N0320-480PRM/FZ
Condition:
Used – Inspected and Pulled from Working Environment
Seller Notes:
Includes 50 wafers stored in three original wafer carrier trays
Country/Region of Manufacture:
United States
Application / Use Case:
Semiconductor fabrication, R&D, MEMS, photolithography
Form Factor:
4-inch (100mm) round wafer, 1 flat
Condition Notes:
Silicon Quest International 4in N-Type polished silicon wafers inspected and in good condition. Pulled from a working semiconductor environment. Stored in original carrier trays with labels and ACCEPT QC stamps intact.
View AllClose
