Multi-Contact PV-JB/2 Solar Panel Junction Box 20A 600V MC3 32.7020.060

(No reviews yet) Write a Review
SKU:
44092
MPN:
PV-JB/2
Condition:
New
Availability:
Currently out of stock — contact us for availability.
Weight:
1.00 LBS
Shipping:
Calculated at Checkout
  • Multi-Contact PV-JB/2 solar junction box closed top view with two 22-inch MC3 leads extended
  • Multi-Contact PV-JB/2 junction box open showing two-terminal block interior and MC3 leads
  • Close-up of PV-JB/2 interior showing dual terminal clips and cable strain relief fittings
  • Close-up of MC3 male and female connector ends on PV-JB/2 leads
  • Multi-Contact PV-JB/2 top label showing model name, 4mm² rating, and IP65 enclosure marking
  • Multi-Contact PV-JB/2 junction box bottom view with MC3 leads spread, showing ribbed housing
  • Close-up of MC PV SOLARCABLE 2.5mm² wire jacket printing on the MC3 leads
$7.80
Was: $16.00

This item is temporarily unavailable. Please view our recommended, in-stock alternatives directly below.

Description

Multi-Contact PV-JB/2 Solar Panel Junction Box 20A 600V MC3 32.7020.060

The Multi-Contact PV-JB/2 is a weatherproof solar panel junction box designed to enclose and protect the exposed solder points or short wire terminals at the back of a photovoltaic module. This stock came out of Unisolar and arrives prewired with two 22-inch MC3 leads — one positive, one negative — fitted with both male and female MC3 connectors for quick series or parallel connections between panels.

Specifications & What's Included

  • Manufacturer Part Number: 32.7020.060
  • Voltage rating: 600–1000V DC
  • Current rating: 20A
  • Wire gauge: 14 AWG / 2.5 mm² (marked MC PV SOLARCABLE 2.5mm² on jacket)
  • Wire insulation cross-section: 4 mm² (per lid label)
  • Enclosure rating: IP65 (weatherproof)
  • Terminal blocks: 2 (positive and negative), slide-in clip style
  • Lead length: approximately 22 inches per lead
  • Connectors: Male and Female MC3 plug connectors (one each, positive and negative)
  • Attaches to panel surface with adhesive (not included); Multi-Contact recommends Dow Corning Sylgard 577 Primerless Silicone
  • Fits MC3 plug connector system
  • Designed for thin-film / thin-layer PV modules
  • New old stock sourced from Unisolar; may not include original retail packaging
