The GNP Computers 1-501842 is a demarc (demarcation) BNC connector PCB board, Revision A, with a date code of 980619 (June 1998). The board carries a large array of BNC coaxial connectors organized into labeled Transmitter and Receiver sections, serving as a structured signal interface and handoff point between transmission equipment and connected cabling or systems.

Specifications & What's Included

• Manufacturer: GNP Computers (PDSi)
• PCB Part Number: 1-501842
• Revision: Rev A
• Date Code: 980619 (June 1998)
• Connector Type: BNC (coaxial), multiple connectors in array
• Board Sections: Transmitter (TX) and Receiver (RX) labeled rows of BNC connectors
• Visible TX ports: TX7, TX9, TX11, TX13 and additional TX connectors across the board
• Rear side: Three black shielded/ferrite component modules and SMD passive components
• Form Factor: PCB / card module
• Board only — no cables or accessories included
