Description
Decibel DB871H83-X 830-900 MHz Cellular Panel Antenna 83° Motorola CellCite
The Decibel DB871H83-X is an 830–900 MHz outdoor panel antenna designed for cellular base station applications including Motorola CellCite installations. It provides an 83° horizontal 3 dB beamwidth, making it a sector-coverage antenna suited to cell site deployments requiring controlled directional coverage across the 800/900 MHz cellular band. The unit is housed in a weatherproof white radome enclosure with a rear-mounted N-female coaxial connector and includes integrated dual pole-mount clamp hardware.
Specifications & What's Included
- Model: DB871H83-X
- Manufacturer: Decibel Products, Dallas, Texas, USA
- Frequency Range: 830–900 MHz
- Horizontal 3 dB Beamwidth: 83°
- Connector: N-female coaxial (rear-mounted)
- Enclosure: Outdoor weatherproof white radome
- Mounting: Dual pole-mount clamp hardware (included, attached to rear)
- Compatible with: Motorola CellCite cell site systems and similar 800/900 MHz infrastructure
Applications
The DB871H83-X is a sector panel antenna built for the 800/900 MHz cellular frequency bands, which were the primary frequencies used in first- and second-generation (1G/2G) cellular networks across North America. Decibel Products was a well-known Dallas-based manufacturer of RF antennas and related components for cellular infrastructure, and their antennas were widely used at cell sites built around Motorola base station equipment — including the CellCite platform — throughout the 1990s and into the 2000s. An 83° horizontal beamwidth places this antenna in the category of sector antennas used to divide cell site coverage into defined angular zones, typically as part of a three-sector or similar configuration. This type of antenna connects directly to the base station transceiver or tower-mounted amplifier via a coaxial feed line at the N-female port. Units like this remain useful for maintaining legacy 800/900 MHz infrastructure, for SMR (Specialized Mobile Radio) systems, for wireless repeater installations, and for RF testing and range setups operating in the cellular band.
This Decibel DB871H83-X 830–900 MHz cellular panel antenna has been inspected and is in good used condition. The white weatherproof radome enclosure shows some surface scuffing and minor soiling consistent with outdoor use, and the rear panel shows light discoloration near the connector area. The N-female coaxial connector shows some surface oxidation around the flange but appears intact. The dual pole-mount clamp hardware on the rear is present and complete. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Decibel |
Model: |
DB871H83-X |
MPN: |
DB871H83-X |
Type: |
Cellular Panel Antenna |
SKU: |
30166 |
Frequency Range: |
830–900 MHz |
Horizontal Beamwidth: |
83° |
Mounting Type: |
Pole Mount |
Connector Type: |
N-Female (coaxial) |
Compatible With: |
Motorola CellCite cell site systems |
Application: |
Cellular base station, SMR, 800/900 MHz wireless |
Country/Region of Manufacture: |
United States |
Form Factor: |
Outdoor Panel |
Seller Notes: |
Includes dual pole-mount clamp hardware on rear of antenna |
Condition: |
Used – Inspected and Pulled from Working Environment |
Condition Notes: |
Decibel DB871H83-X 830–900 MHz cellular panel antenna inspected and in good used condition. Radome shows light scuffing from outdoor use; N-female connector intact; dual pole-mount clamp hardware included. Please contact us with questions. |
