Yaskawa SGML-04AF14 AC Servo Motor 400W 200V w/ BD-103-005-P110 1:9 Gearbox
This is a Yaskawa SGML-04AF14 AC Servo Motor paired with a Nidec-Shimpo VRSF-LB-S9C-400 gearbox (part number BD-103-005-P110) in a complete belt-driven assembly. The motor is rated at 400W and drives the gearbox through a Unitta 520-5M timing belt and dual-pulley arrangement, with the gearbox providing a 1:9 reduction ratio. The assembly includes a precision bolt-circle output flange on the gearbox and mounts on an aluminum plate structure.
Specifications & What's Included
- Motor Manufacturer: Yaskawa Electric Corporation, Japan
- Motor Model: SGML-04AF14
- Motor Type: AC Servo Motor
- Power Rating: 400W
- Voltage: 200V
- Current: 2.6A
- Torque: 1.27 N·m
- Speed: 3000 RPM
- Insulation Class: B
- Order Number: R10296-197-11
- Gearbox Manufacturer: Nidec-Shimpo
- Gearbox Model: VRSF-LB-S9C-400
- Gearbox Part Number: BD-103-005-P110
- Gear Ratio: 1:9
- Drive Belt: Unitta 520-5M timing belt
- Output: Precision bolt-circle flange face with center bore shaft
- Connector: Multi-pin rectangular motor connectors on wiring harness
- Mounting: Aluminum plate/bracket assembly
- Country of Manufacture: Japan
Applications
The Yaskawa SGML series is a line of compact AC servo motors designed for precision motion control in industrial automation. Paired with a Nidec-Shimpo precision gearbox at a 1:9 ratio, this assembly is suited for indexing, rotary positioning, and multi-axis motion applications where controlled torque multiplication and accurate positioning are required. These servo motor and gearbox combinations are commonly found in semiconductor handling equipment, robotics, automated assembly machinery, CNC peripherals, and pick-and-place systems. The SGML series dates from the late 1990s era of Yaskawa's Sigma servo family and remains compatible with Yaskawa Sigma-series servo amplifiers and drives. The Nidec-Shimpo VRSF series gearboxes are known for low backlash and are a standard pairing for precision servo applications in factory automation.
This Yaskawa SGML-04AF14 AC Servo Motor with BD-103-005-P110 gearbox assembly has been inspected and appears to be in good used condition. The teal gearbox body shows light surface oxidation and general shop wear consistent with prior industrial use. The output shaft, flange face, and aluminum components show some discoloration and minor scuffing. The Unitta timing belt and pulleys appear intact. The motor wiring harness and multi-pin connectors are present. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
