Varian 01-00064 CMC 1527A High Voltage Power Assembly Klystron RF Supply MED
High voltage power assembly designed for Klystron RF power supply systems. This is a complete sub-assembly pulled from a working Varian M.E.D. RF power supply unit.
Specifications & What's Included
- Model: CMC 1527A (MPN 01-00064, Rev J)
- Primary Input: 115V AC
- Secondary Output: 12V DC (relay coil supply)
- Three transformers: Varian 01-00064, Stancor P-8657, Stancor C-2722
- Two Potter & Brumfield KUP14D15 12VDC relays
- Sprague 622D capacitor: 6300 µF, 35 VDC
- Varian resistor assembly (8330L 2801)
- 1500V RMS insulation rating (Stancor transformer)
- Open frame, panel-mount sub-assembly: 20.5" x 6.5" x 6"
Applications
This assembly type functions as a support power supply within Klystron RF generator systems, which were used in medical linear accelerators, industrial RF processing, and telecommunications infrastructure. The 12V relay supply and high-voltage conditioning circuitry are integral to Varian M.E.D. accelerator platforms. These assemblies were commonly found in institutional radiotherapy and research installations.
Condition: Used
This Varian CMC 1527A High Voltage Power Assembly (P/N 01-00064) has been inspected and is in good used condition. It was pulled from a Varian Klystron RF Power Supply where it was in active use and functional. The assembly shows age-appropriate patina and dust typical of older RF power equipment, but all components — including the Stancor transformers, AMF Potter & Brumfield relays, Sprague capacitor, and Varian resistor — appear intact with no obvious damage. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
This Varian CMC 1527A High Voltage Power Assembly (P/N 01-00064) has been inspected and is in good used condition. It was pulled from a Varian Klystron RF Power Supply where it was in active use and functional. The assembly shows age-appropriate patina and dust typical of older RF power equipment, but all components — including the Stancor transformers, AMF Potter & Brumfield relays, Sprague capacitor, and Varian resistor — appear intact with no obvious damage. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
