Tektronix 7A18 7A18N 070-1126-01 Dual Trace Amplifier Instruction Manual
This is the original printed Instruction Manual for the Tektronix 7A18 and 7A18N Dual Trace Amplifier plug-in modules, published by Tektronix under part number 070-1126-01. It is a comprehensive factory manual covering the full range of technical information needed to operate, calibrate, troubleshoot, and repair these plug-in units.
Specifications & What's Included
- Manufacturer: Tektronix
- For Models: 7A18 and 7A18N Dual Trace Amplifier
- Publication / Part Number: 070-1126-01
- Document Type: Instruction Manual
- Format: Printed, spiral-bound hard copy
- Language: English
- Sections included: Specifications, Operating Instructions, Circuit Description, Maintenance, Calibration (recalibration interval, performance check, adjustment procedures), Electrical Parts List, Diagrams and Circuit Board Illustrations, Mechanical Parts List
- Full schematic fold-out diagrams included (Channel 1 and Channel 2 Input Amplifier schematics, Display Mode and Trigger Switching diagram)
- Compatible with Tektronix 7000 Series mainframe oscilloscopes
Applications
The Tektronix 7A18 and 7A18N are vertical amplifier plug-in modules designed for use in the Tektronix 7000 Series oscilloscope mainframes — a highly regarded modular oscilloscope platform that Tektronix produced from the early 1970s through the mid-1980s. The 7A18 is a dual-trace, 75 MHz vertical amplifier offering two independent input channels with selectable coupling and sensitivity, making it one of the most common and versatile plug-ins in the 7000 Series family. Compatible mainframes include the 7603, 7613, 7623, 7633, 7703, and others. This Instruction Manual is an essential reference for technicians performing calibration, component-level repair, or routine maintenance on these plug-in modules. It is also sought after by vintage instrument collectors and hobbyists restoring 7000 Series oscilloscopes to working order. Original Tektronix factory manuals for these plug-ins have become increasingly scarce as the instruments age, making a clean copy with intact schematics particularly valuable to the repair community.
This Tektronix 7A18/7A18N Dual Trace Amplifier Instruction Manual (P/N 070-1126-01) has been inspected and is in good used condition. The spiral binding is intact and the blue cover shows light shelf wear consistent with normal storage. All pages are present and legible, including the full schematic fold-outs. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
Tektronix |
Model: |
7A18/7A18N |
MPN: |
070-1126-01 |
Type: |
Instruction Manual |
SKU: |
37631 |
Condition: |
Used – Inspected |
Document Type: |
Instruction Manual |
For Make/Model: |
Tektronix 7A18 / 7A18N Dual Trace Amplifier |
Compatible With: |
Tektronix 7000 Series Oscilloscopes |
Language: |
English |
Format: |
Printed / Hard Copy |
Publication Number: |
070-1126-01 |
Sections Covered: |
Specs, Operation, Circuit Description, Maintenance, Calibration, Parts Lists, Schematics |
Country/Region of Manufacture: |
United States |
Seller Notes: |
Manual only; no instrument included. All pages present and legible. |
Condition Notes: |
Tektronix 7A18/7A18N Dual Trace Amplifier Instruction Manual (070-1126-01) inspected and in good used condition. Spiral binding intact, cover shows light shelf wear. All pages present and legible including schematics. |
