Tekdata C224001-03 Rev F PCB Han-DD 72M Connector Board CS2000103 1995

(No reviews yet) Write a Review
SKU:
26271
MPN:
C224001-03 F
Condition:
New
Availability:
Usually ships within 1-2 business days.
Weight:
3.00 LBS
Shipping:
Calculated at Checkout
  • Tekdata C224001-03 Rev F PCB – top view showing multiple white JST-style connectors and green PCB
  • Tekdata C224001-03 Rev F PCB – angled view showing Han-DD 72M high-density male connector on panel bracket
  • Tekdata C224001-03 PCB – board underside close-up showing handwritten date code C293 09/95 and TEKDATA marking
  • Tekdata C224001-03 Rev F PCB – silkscreen label close-up showing part number C224001-03 Rev F
  • Tekdata CS2000103 Rev D – secondary board marking close-up showing CS2000103 REV D silkscreen
  • Han-DD 72M connector close-up – showing 10A 250V rating stamped on connector body
  • Han-DD 72M connector pin-face view – showing 72-pin high-density male contact array and locking hardware
$45.00
Was: $90.00
Current Stock: 2

Sold Out

Description

Tekdata C224001-03 Rev F PCB Han-DD 72M Connector Board CS2000103 1995

This is a Tekdata C224001-03 Rev F printed circuit board assembly featuring a panel-mounted Han-DD 72M high-density male connector. The board carries the secondary reference CS2000103 Rev D on its silkscreen and is date-coded to September 1995. It is a compact interface PCB designed to route multi-pin signals through a heavy-duty industrial connector, typical of the type used in machine control, automation, and industrial equipment interconnect applications.

Specifications & What's Included

  • Manufacturer: Tekdata
  • Part Number: C224001-03
  • Revision: Rev F
  • Secondary Board Reference: CS2000103 Rev D
  • Date Code: 09/1995 (handwritten: C293 09/95 TEKDATA)
  • Main Connector: Han-DD 72M — 72-pin high-density male, panel-mount
  • Connector Rating: 10A, 250V
  • Connector Style: Han-DD (Harting DD series compatible form factor)
  • Board Interface: Multiple JST-style white header connectors on PCB (signal routing)
  • PCB Color: Green, standard FR4-type construction
  • Form Factor: Card / Module with mounting bracket

Applications

Han-DD series connectors are a Harting-standard high-density rectangular connector widely used in industrial automation, CNC machinery, robotics, and modular machine control systems. The Han-DD 72-pin format allows a large number of signal lines to pass through a single panel-mount interface point, making it well suited for machine tool interconnects, servo drive signal harnesses, and I/O panel assemblies. Tekdata, a UK-based electronics manufacturer, has produced custom PCB assemblies and interface boards for industrial control and data communications equipment. Boards of this type typically serve as interface or breakout PCBs within a larger system enclosure, bridging backplane or cable harness signals to individual board-level circuits. This particular assembly dates from 1995 and is representative of mid-1990s industrial PCB design.

Condition: Open Box
This Tekdata C224001-03 Rev F PCB interface board is new and unused. It may be out of its original packaging, but it shows no signs of use or wear. The board and Han-DD 72M connector appear clean and undamaged. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
