STS Inc Equalizer 2 Satellite IF Equalizer 19" Rackmount 2U EQ1 EQ2 EQ3 Satcom RF
The STS Inc Equalizer 2 is a 19-inch 2U rackmount satellite intermediate frequency (IF) equalizer designed for use in satellite ground station and microwave communications systems. It provides three independent equalization channels (EQ1, EQ2, EQ3) along with a dedicated IF path, and includes front-panel fault indicators, IF level test points, and a lamp test function for system diagnostics. The unit accepts either 115V or 220V AC power, selectable via the front-panel fuse configuration.
Specifications & What's Included
- Manufacturer: STS Inc
- Model: Equalizer 2
- Form Factor: 19" Rackmount, 2U
- Equalization Channels: 3 independent channels — EQ1, EQ2, EQ3
- IF Input/Output: BNC connectors — J1 (IF IN) and J10 (IF OUT) on rear panel
- Front Panel — INPUTS section: EQ1, EQ2, EQ3, and IF BNC-style input connectors
- Front Panel — OUTPUTS section: EQ1, EQ2, EQ3 BNC-style output connectors
- Front Panel — FAULTS section: individual LED fault indicators for EQ1, EQ2, EQ3, IF, Fuse, and Fail
- Front Panel — TEST POINTS section: IF Level test jacks for EQ1, EQ2, EQ3, +5VDC, and GND (banana-type)
- Front Panel — Lamp Test button for fault indicator verification
- Power: 115V AC (1/4A fuse) or 220V AC (1/8A fuse), selectable at front-panel fuse block
- Power switch: front-panel rotary ON/OFF with green LED power indicator
- Rear Panel — Control Connectors: J11 and J12 (DB-15 female)
- AC Input: IEC C14 inlet on rear panel
- Interior: internal equalizer modules, wiring harness, and dual high-voltage power supply sections (labeled DANGER HIGH VOLTAGE)
- Top cover: red-painted steel with aluminum rack ears
- Includes: unit only
Applications
The Equalizer 2 is a specialized piece of satellite ground station equipment used to compensate for amplitude and group delay distortions introduced in the IF signal path — typically between a satellite modem or demodulator and the up/downconverter chain. In satellite communications systems, the IF section (commonly 70 MHz or 140 MHz) carries the modulated carrier between indoor and outdoor RF equipment, and amplitude or phase distortions in cables, combiners, or amplifiers along that path can degrade link performance. An IF equalizer like this unit corrects those distortions by applying an inverse transfer function, improving the quality of the received or transmitted signal. The three-channel architecture (EQ1, EQ2, EQ3) allows the unit to serve in systems where multiple IF paths or carriers require independent equalization. Units of this type were standard in satellite teleport facilities, military satcom installations, and broadcast uplink stations from the 1980s through the early 2000s, and continue to be used in legacy ground station infrastructure where this class of analog IF hardware remains in service.
This STS Inc Equalizer 2 satellite IF equalizer has been inspected and is in good used condition. It was pulled from a working satcom environment where it was in active use. The red top cover shows light scuffing and general surface wear consistent with rack-mounted field use. The front panel controls, BNC connectors, and fault indicator section appear intact. The rear DB-15 control connectors and BNC IF IN/OUT ports show normal wear. Interior photos show the internal modules and wiring are present and intact, with high-voltage power supply sections visible. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
STS Inc |
Model: |
Equalizer 2 |
MPN: |
Equalizer 2 |
Type: |
Satellite IF Equalizer |
SKU: |
31516 |
Form Factor: |
19" Rackmount, 2U |
Number of EQ Channels: |
3 (EQ1, EQ2, EQ3) |
IF Channels / Paths: |
IF IN, IF OUT (BNC connectors) |
Connector Types: |
BNC (IF IN/OUT), DB-15 (J11, J12 rear control) |
Rear Connectors: |
J11 DB-15, J12 DB-15, J1 IF IN BNC, J10 IF OUT BNC |
Fault Indicators: |
EQ1, EQ2, EQ3, IF, Fuse, Fail LEDs on front panel |
Test Points: |
IF Level: EQ1, EQ2, EQ3, +5VDC, GND (front panel) |
Power Requirements: |
115V AC (1/4A fuse) or 220V AC (1/8A fuse) |
Fuse Ratings: |
1/8A at 220V; 1/4A at 115V |
Power Switch: |
Front panel ON/OFF rotary switch with green LED indicator |
Application: |
Satellite ground station IF path equalization, Satcom |
Frequency Band: |
IF (Intermediate Frequency) — Satcom/Microwave |
Condition: |
Used – Pulled from Working Environment |
Seller Notes: |
Unit only; pulled from working satcom environment |
Country/Region of Manufacture: |
United States |
Condition Notes: |
STS Inc Equalizer 2 satellite IF equalizer — inspected, in good used condition. Pulled from a working satcom environment. Light surface wear on chassis. Front panel connectors and controls intact. Please contact us with any questions. |
