Description
Relay PC Board 280295-001 1602-0400 Rev A 4-Relay DIN Rail DB25 Fill/Run Ctrl
This is a multi-relay PC board assembly (part number 280295-001) built around a green DIN rail-mount housing. The PCB itself is marked P/N 1602-0400 Rev A and carries four relay positions populated with relay components. The board interfaces to a host system via a DB25 (D-Sub 25-pin) connector and provides multiple screw terminal blocks along its perimeter for field wiring. A toggle switch on the board selects between FILL and RUN operating modes, and red LED indicators provide status feedback.
Specifications & What's Included
- Assembly Part Number: 280295-001
- PCB Part Number: 1602-0400 Rev A
- Number of relay positions: 4 (all populated)
- Housing: Green DIN rail-mount plastic enclosure
- System connector: DB25 (D-Sub 25-pin)
- Field wiring: Green screw terminal blocks along board perimeter
- Toggle switch: FILL / RUN mode selection (up = Initial Fill, down = Run)
- Status indicators: Red LED indicators
- Terminal labels visible: BL, S0E, SPILL, 3CRE,.32
- Includes relay PC board in DIN rail housing only — no cables or external hardware
Applications
Relay PC boards of this type are used in industrial process control and automated dispensing or fluid management systems, where a centralized relay card switches multiple output loads under direction from a host controller or PLC communicating over a parallel interface like DB25. The FILL/RUN mode toggle is characteristic of liquid-level or fluid dispensing control systems — FILL mode typically initializes or pre-charges a system, while RUN mode transitions it to normal operating logic. These boards are commonly found in automated filling equipment, industrial process controllers, and similar systems where multiple relay outputs need to be driven from a single interface connector. The DIN rail housing allows the board to mount directly inside a control cabinet on standard 35 mm DIN rail.
This Relay PC Board (P/N 280295-001 / PCB 1602-0400 Rev A) has been pulled from a working environment and is in good used condition. The board, DIN rail housing, and screw terminals all appear clean and undamaged in our photos. It has not been powered up or tested at our facility. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Unbranded |
Model: |
280295-001 |
MPN: |
280295-001 |
Secondary Model: |
1602-0400 |
PCB Part Number: |
1602-0400 Rev A |
Revision: |
Rev A |
SKU: |
34431 |
Type: |
Relay PC Board |
Number of Relays: |
4 |
Form Factor: |
DIN Rail Mount |
Connector Type: |
DB25 (D-Sub 25-pin) |
Terminal Type: |
Screw Terminal Blocks |
Housing Color: |
Green |
Control Modes: |
Fill / Run (toggle switch selectable) |
LED Indicators: |
Yes — red LEDs |
Seller Notes: |
Relay PC board only — no cables or external hardware included. |
Condition Notes: |
Relay PC Board 280295-001 (PCB 1602-0400 Rev A) pulled from a working environment and in good used condition. Board and housing appear clean and undamaged. Not powered or tested at our facility. |
