Description
Keithley PCIP-AWFG 24836 5 MHz 12-Bit Arbitrary Waveform Generator User Manual Rev A 1990
User manual for the Keithley PCIP-AWFG arbitrary waveform generator board. This ISA card generates custom waveforms up to 5 MHz with 12-bit resolution for test and measurement applications.
Specifications & What's Included
- Model: PCIP-AWFG (Part No. 24836)
- Frequency Range: 5 MHz
- Resolution: 12-Bit
- Form Factor: PC Card / ISA Board
- Revision: A (April 1990)
- Includes: 3 Floppy Disks
- Manufacturer: Keithley Metrabyte/Asyst/DAC
Applications
Used in laboratory and industrial test setups for signal generation, circuit validation, and waveform development.
Please note: We may have multiple units of this item in stock. The unit you receive may vary slightly from the one shown in the photos. All units are functionally equivalent and inspected to the same standard.
Condition: Used
This Keithley PCIP-AWFG Arbitrary Waveform Generator User Manual (Part No. 24836, Rev A) is in good used condition with normal shelf wear. All pages appear present and legible. Includes 3 floppy disks as noted. Please view our photo set and contact us if you have any questions.
This Keithley PCIP-AWFG Arbitrary Waveform Generator User Manual (Part No. 24836, Rev A) is in good used condition with normal shelf wear. All pages appear present and legible. Includes 3 floppy disks as noted. Please view our photo set and contact us if you have any questions.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Keithley |
Model: |
PCIP-AWFG |
MPN: |
24836 |
SKU: |
29909 |
Condition: |
Used – Inspected |
Document Type: |
User Manual |
Revision: |
Revision A |
Publication Date: |
April 1990 |
Publisher: |
Keithley Metrabyte/Asyst/DAC |
Frequency Range: |
5 MHz |
Resolution: |
12-Bit |
Instrument Type: |
Arbitrary Waveform Generator |
Form Factor: |
PC Card / ISA Board |
Includes: |
3 Floppy Disks |
Seller Notes: |
Includes original 3 floppy disks. Rev A, April 1990. |
Country of Manufacture: |
United States |
Compatible With: |
Keithley PCIP-AWFG 5 MHz 12-Bit Arbitrary Waveform Generator |
Condition Notes: |
This Keithley PCIP-AWFG Arbitrary Waveform Generator User Manual (Part No. 24836, Rev A) is in good used condition with normal shelf wear. All pages appear present and legible. Includes 3 floppy disks as noted. Please view our photo set and contact u |
