HP 33120A Arbitrary Waveform Function Generator User's Guide Manual
This is the original operating manual and user's guide for the HP 33120A Arbitrary Waveform Function Generator. The 33120A is a versatile signal generation instrument capable of producing sine, square, triangle, and arbitrary waveforms. This comprehensive guide covers setup, operation, programming, and reference information needed to fully use the instrument.
Specifications & What's Included
- Manufacturer: Hewlett-Packard (HP)
- Instrument Model: 33120A
- Document Type: User's Guide / Operating Manual
- Equipment Category: Arbitrary Waveform Function Generator
- Content: Complete operating and programming reference
- Language: English
- Format: Printed manual
- Condition: Used, all pages present and legible
Applications
The HP 33120A is an industry-standard function generator designed for laboratory, bench-top, and testing environments. It is used for signal generation in circuit testing, system verification, research, and educational applications. The 33120A supports multiple waveform types and programmable output parameters, making it suitable for a wide range of analog and digital test scenarios. This manual is essential for operators and technicians needing to configure, program, and troubleshoot the instrument. The guide includes front-panel operation procedures, remote programming commands via GPIB and RS-232 interfaces, and detailed reference information. The 33120A was produced during the 1980s–1990s era and remains in use today in legacy test systems, educational labs, and vintage electronics restoration projects.
This HP 33120A Arbitrary Waveform Function Generator User's Guide is in good used condition. The manual is complete with all pages present and legible. It shows normal shelf wear consistent with age and use. Please view our photo set and contact us with any questions before purchasing. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
Hewlett-Packard |
Model: |
33120A |
MPN: |
33120A |
Type: |
User's Guide / Operating Manual |
SKU: |
37848 |
Document Type: |
User's Guide |
Equipment Category: |
Arbitrary Waveform Function Generator |
For Make/Model: |
HP / Hewlett-Packard 33120A |
Language: |
English |
Format: |
Printed Manual |
Seller Notes: |
Used original manual — complete and legible |
Country/Region of Manufacture: |
USA |
Review Status: |
Auto-Approved (needs review) 2026-07-09 |
Condition Notes: |
HP 33120A User's Guide in good used condition. Complete, all pages legible, normal shelf wear. |
