Carnel Labs NM-65T 1-10 GHz EMI Radio Interference Analyzer Receiver
Carnel Labs
$600.00Was: $1,200.00Carnel Labs NM-65T 1-10 GHz EMI Radio Interference Analyzer ReceiverBenchtop EMI analyzer for detection and measurement of radio frequency interference across the 1–10 GHz frequency range. Used for...25015- SKU:
- 25015
- Availability:
- Usually ships within 1–2 business days.
- Weight:
- 38.00 LBS
- Brand:
- Carnel Labs
- Model:
- NM-65T
- MPN:
- NM-65T
- SKU:
- 25015
- Type:
- EMI Radio Interference Analyzer / Receiver
- Condition:
- As-Is / For Parts or Not Working
- Frequency Range:
- 1 GHz to 10 GHz
- Frequency Bands:
- 1.0–2.0 GHz, 2.0–4.4 GHz, 4.4–10.0 GHz
- IF Bandwidth:
- 0.1 MHz, 1.0 MHz, 10 MHz (3 selectable)
- Dynamic Range:
- 60 dB (logarithmic IF amplifier display)
- Measurement Range:
- 120 dB total (three 20 dB attenuator steps)
- Attenuator Steps:
- 3 x 20 dB steps (0 dB, +20 dB, +40 dB)
- Display Type:
- Analog panel meter (microvolts / dB / dBm)
- Meter Scales:
- Microvolts, dB referred to 1uV, -dBm
- Power Source:
- AC mains via IEC inlet; battery (Recharge/Operate)
- Measurement Type:
- Conducted and radiated RF / EMI
- Standards Compliance:
- Military and commercial EMI test specifications
- Form Factor:
- Benchtop
- Seller Notes:
- Sold as-is for parts or repair; includes internal RF modules visible in photos
- Condition Notes:
- Carnel Labs NM-65T EMI Analyzer sold as-is for parts or repair. Not tested or guaranteed functional. Top cover absent; internal RF modules show corrosion. Front panel and meter appear intact. Please contact us with questions.
- California Prop 65 Warning:
- WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov
$600.00Was: $1,200.00 -
Carnel Labs CCI-7 Controller Counter Interface EMI NM7 Receiver GPIB 100-240V
Carnel Labs
$325.00Was: $650.00Carnel Labs CCI-7 Controller Counter Interface EMI NM7 Receiver GPIB 100-240V Benchtop/rackmount controller interface for EMI and EMC testing applications. Manages sweep control and receiver...25053- SKU:
- 25053
- Availability:
- Usually ships within 1-2 business days.
- Weight:
- 46.00 LBS
- Brand:
- Carnel Labs
- Model:
- CCI-7
- MPN:
- CCI-7
- Secondary Model:
- Eaton Advanced Electronics CCI-7
- Type:
- Controller Counter Interface
- SKU:
- 25053
- Compatible With:
- NM Series 7 Receivers
- Interface Type:
- GPIB
- Number of Controller Cards:
- 4
- Input Voltage:
- 100-120VAC / 200-240VAC, 50-400Hz
- Fuse Rating 100-120V:
- 3.0A SB
- Fuse Rating 200-240V:
- 1.5A SB
- Application:
- EMI / EMC Testing, Receiver Sweep Control
- PWBA Card 1 Part Number:
- PWBA 4-006039-001 REV B (qty 4)
- PWBA Card 2 Part Number:
- PWBA 4-006038-001 REV C (qty 3)
- PWBA Card 3 Part Number:
- PWBA 4-006037-001 (qty 1)
- PWBA Card 4 Part Number:
- PWBA 4-006036-001 (qty 1)
- PWBA Card 5 Part Number:
- PWBA 4-006035-001 (qty 1)
- PWBA Card 6 Part Number:
- PWBA 4-006034-001 (qty 1)
- Form Factor:
- Benchtop / Rackmount Chassis
- Condition:
- Used – Inspected
- Seller Notes:
- Includes all internal PWBA receiver controller cards as listed; GPIB interface.
- Condition Notes:
- Carnel Labs CCI-7 Controller Counter Interface. Inspected and in good condition. All internal PWBA cards present as listed. Green TESTED sticker visible on rear panel. Normal lab wear.
- California Prop 65 Warning:
- WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov
$325.00Was: $650.00
