Avantek ATM-18033 12-18 GHz Wideband Amplifier RF Microwave Assembly w/ Narda S213D
This is a multi-component RF and microwave signal assembly built around an Avantek ATM-18033 wideband small signal amplifier covering 12.0 to 18.0 GHz (Ku-band). The sub-modules are mounted on a common aluminum chassis with SMA coaxial interconnects and a D-Sub control/interface connector, forming a ready-to-integrate RF signal chain. The assembly includes an amplifier, digital attenuator, SPST switch, switching modules, and fixed attenuators from well-known microwave component manufacturers.
Specifications & What's Included
- Qty 1 — Avantek ATM-18033 Wideband Small Signal Amplifier, 12.0–18.0 GHz; Made in the U.S.A.; date code 1996
- Qty 1 — VMC (Vectronics Microwave Corp) DAD1114-80 Digital Attenuator; SN 184
- Qty 1 — Narda S213D SPST Switch, 2–18 GHz
- Qty 2 — Teledyne Microwave CS33SIC-T Module, 24–30 VDC
- Qty 1 — Varian VSR 9050BTA
- Qty 1 — Microwave Associates 8R45F Module
- Qty 1 — ARRA 9412-6 Fixed Attenuator
- Qty 1 — ARRA 9412-10 Fixed Attenuator
- Chassis: aluminum frame, chassis part number 01-P2443H012 (visible on rear panel)
- Interconnects: SMA coaxial connectors throughout
- Interface: D-Sub multi-pin control connector
- Control voltage: 24–30 VDC (Teledyne modules)
Applications
Avantek ATM-series amplifiers are wideband, low-noise GaAs MESFET amplifiers designed for microwave signal amplification across the Ku-band (12–18 GHz), a range covering satellite communications downlinks, radar intermediate frequency chains, electronic warfare subsystems, and microwave test and measurement setups. Avantek was a leading U.S. manufacturer of microwave and RF components and semiconductors, later acquired by Hewlett-Packard (HP) in the early 1990s, which is why Avantek products are sometimes listed under the HP brand. Assembled signal chains like this one — combining an amplifier, a digitally controlled attenuator, an SPST switch, and fixed attenuators on a single chassis — are typical of rack-mounted or bench-level RF subsystems used in defense electronics, satellite ground station equipment, and microwave test benches. The Narda S213D SPST switch and ARRA fixed attenuators are standard precision microwave components used in signal routing and level-setting applications. This type of integrated sub-assembly is well-suited for use as a receive chain element, a signal conditioning stage, or a gain-control section in a larger microwave system.
This Avantek ATM-18033 12-18 GHz RF Microwave Amplifier Assembly has been inspected and is in good used condition. The assembly was pulled from a working environment where it was actively in use and functional. All sub-components are present as listed: the Avantek ATM-18033 wideband amplifier, VMC DAD1114-80 digital attenuator, Narda S213D SPST switch, two Teledyne CS33SIC-T modules, Varian VSR 9050BTA, Microwave Associates 8R45F module, and both ARRA 9412-6 and 9412-10 attenuators. The chassis and modules show typical wear consistent with lab or system use. SMA connectors and the D-Sub interface connector appear intact. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Avantek |
Model: |
ATM-18033 |
MPN: |
ATM-18033 |
Type: |
RF Microwave Amplifier Assembly |
SKU: |
49560 |
Frequency Range: |
12 to 18 GHz |
Amplifier Type: |
Wideband Small Signal Amplifier |
Frequency Band: |
Ku-Band |
Country/Region of Manufacture: |
United States |
Form Factor: |
Chassis/Module Assembly |
Included Component 1: |
Avantek ATM-18033 Wideband Amplifier 12-18 GHz (Qty 1) |
Included Component 2: |
VMC Vectronics DAD1114-80 Digital Attenuator (Qty 1) |
Included Component 3: |
Narda S213D SPST Switch 2-18 GHz (Qty 1) |
Included Component 4: |
Teledyne Microwave CS33SIC-T Module 24-30 VDC (Qty 2) |
Included Component 5: |
Varian VSR 9050BTA (Qty 1) |
Included Component 6: |
Microwave Associates 8R45F Module (Qty 1) |
Included Component 7: |
ARRA 9412-6 Attenuator (Qty 1) |
Included Component 8: |
ARRA 9412-10 Attenuator (Qty 1) |
Connector Type: |
SMA (coaxial), D-Sub |
Control Voltage: |
24-30 VDC (Teledyne modules) |
Narda Switch Model: |
S213D, 2-18 GHz SPST |
VMC Attenuator Model: |
DAD1114-80 Digital Attenuator |
Condition: |
Used – Pulled from Working Environment |
Seller Notes: |
Complete multi-component RF assembly; all sub-modules listed above are included as shown. |
Condition Notes: |
Avantek ATM-18033 12-18 GHz RF amplifier assembly inspected and in good used condition. Pulled from a working environment where it was actively in use and functional. All listed sub-components present. SMA and D-Sub connectors intact. |
