Description
Xantrex XFR Series TM-F1OP-C1XN 1200W Power Supply Operating Manual
This is the original printed Operating Manual for the Xantrex XFR Series programmable DC power supply, publication number TM-F1OP-C1XN. It covers all eleven 1200-watt models in the XFR line and is the primary reference for installation, configuration, operation, and calibration of these supplies. The manual is spiral-bound and printed in English.
Specifications & What's Included
- Manufacturer: Xantrex
- Series: XFR Series Programmable DC Power Supply
- Publication Number (MPN): TM-F1OP-C1XN
- Document Type: Operating Manual
- Format: Printed, spiral-bound
- Language: English
- Power Class Covered: 1200 Watt models
- Models Covered: 6-200, 7.5-140, 12-100, 20-60, 35-35, 40-30, 60-20, 100-12, 150-8, 300-4, 600-2
- Chapter 1 – Features and Specifications: front/rear panel descriptions, electrical specs, environmental and mechanical specs
- Chapter 2 – Installation: setup, AC input/voltage selector, load connections, remote sensing wiring, remote programming sources
- Chapter 3 – Local Operation: standard operation, shutdown function, over-voltage protection (OVP), multiple supply configurations (series, parallel, split)
- Chapter 4 – Remote Operation: analog and digital programming of output voltage and current, remote shutdown, readback signals
- Chapter 5 – Calibration: voltage and current programming/monitor circuit calibration, remote calibration
- Includes List of Figures and List of Tables with dimensional drawings, connector pinouts, and wiring diagrams
Applications
The Xantrex XFR Series is a line of rack-mountable, programmable DC power supplies used in industrial, research, and test-and-measurement environments. These supplies are designed for applications requiring precise, remotely controllable DC output — including automated test systems (ATE), semiconductor burn-in, component characterization, electrochemical processing, and R&D bench work. The XFR line supports both local front-panel control and remote analog or digital programming, making it well suited for integration into larger automated setups. With the 1200W models spanning output voltages from 6V to 600V and currents from 2A to 200A, this series covers a wide range of loads in a single product family. This manual is the essential reference for any engineer or technician commissioning, operating, or servicing an XFR Series unit — particularly valuable when setting up remote programming sources, configuring multiple-supply operation, or performing calibration procedures.
This Xantrex XFR Series TM-F1OP-C1XN 1200W Power Supply Operating Manual is in good used condition. The spiral binding is intact and the pages are clean, complete, and fully legible throughout. The cover shows light shelf wear consistent with prior storage or use. No missing pages, no heavy markings, and no water damage were observed. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Xantrex |
Model: |
XFR Series |
MPN: |
TM-F1OP-C1XN |
SKU: |
37545 |
Type: |
Operating Manual |
Document Type: |
Operating Manual |
For Make/Model: |
Xantrex XFR Series 1200W Power Supply |
Language: |
English |
Format: |
Printed / Spiral Bound |
Models Covered 1: |
6-200, 7.5-140, 12-100, 20-60, 35-35 |
Models Covered 2: |
40-30, 60-20, 100-12, 150-8, 300-4, 600-2 |
Power Rating Covered: |
1200W |
Chapters Covered: |
Features, Installation, Local Operation, Remote Operation, Calibration |
Condition: |
Used – Good |
Seller Notes: |
Original printed Xantrex manual; all pages present and legible |
Country/Region of Manufacture: |
United States |
Condition Notes: |
Xantrex XFR Series TM-F1OP-C1XN Operating Manual in good used condition. Spiral binding intact, all pages present and legible, cover shows light shelf wear. No missing pages or damage. |
