SMC NCDA1F200-3200 Pneumatic Cylinder 32" Stroke 2" Bore 3/8" NPT 250PSI

SMC NCDA1F200-3200 Pneumatic Cylinder 32" Stroke 2" Bore 3/8" NPT 250PSI

This is an SMC medium-duty double-acting pneumatic cylinder designed for industrial automation and machinery control applications. The NCDA1F200-3200 is a reliable workhorse in pneumatic systems, delivering controlled linear motion for a wide range of industrial processes including manufacturing equipment, assembly machinery, material handling, and process control systems.

Specifications & What's Included

• Make: SMC (Nippon Pneumatics)
• Model: NCDA1F200-3200
• Cylinder Type: Double-acting pneumatic cylinder
• Bore Diameter: 2 inches
• Stroke Length: 32 inches
• Maximum Operating Pressure: 250 PSI (1.7 MPa)
• Port Configuration: 3/8" NPT threaded male air ports (extend and retract)
• Duty Class: Medium-duty industrial
• Rod End: Standard configuration
• Mounting: Standard industrial mounting base

Applications

SMC pneumatic cylinders like the NCDA1F200-3200 are standard components in industrial automation systems worldwide. These double-acting cylinders are commonly used in manufacturing machinery, automated assembly lines, material handling equipment, punch presses, injection molding systems, and process control applications where controlled linear motion is required. The 32-inch stroke and 2-inch bore combination is typical for applications requiring extended reach with moderate to high force output. Double-acting design allows both extend and retract strokes to be powered, making these cylinders versatile for machine control, positioning, clamping, and load handling. The 250 PSI rating suits most standard plant air supplies running at 80–100 PSI working pressure with margin for peak demand. This is a Japanese-manufactured unit from the era when SMC became the dominant global pneumatics supplier (1980s onward), and these cylinders remain in active service across manufacturing, food processing, packaging, automotive, and semiconductor industries.
