The SMC MKB20-20RZ is a compact pneumatic rotary clamp cylinder from SMC Corporation's MKB series. It combines linear stroke with a rotary clamping motion in a single actuator body, allowing a workpiece to be secured in one coordinated pneumatic action. With a 20mm bore and 20mm stroke, it is sized for light-duty precision clamping tasks in automated fixtures and tooling systems. The rotation direction on this model is clockwise during clamping. Maximum operating pressure is 1.0 MPa, as indicated on the unit label.

Specifications & What's Included

• Model: SMC MKB20-20RZ
• Bore Size: 20mm
• Stroke Length: 20mm
• Rotation Direction: Clockwise (during clamping)
• Maximum Operating Pressure: 1.0 MPa (visible on unit label)
• Actuation: Pneumatic (air-powered)
• Auto-Switch Mounting: Grooves present for SMC auto-switch sensors
• Sensor Wires: Attached; wire length varies between units
• Country of Manufacture: Japan
• Series: SMC MKB Series

Applications

SMC MKB series rotary clamp cylinders are designed for use in automated manufacturing fixtures where a workpiece must be clamped and held in position during machining, assembly, or inspection operations. The combined rotary-and-clamp motion — sometimes called a swing-and-clamp action — swings the arm clear of the workpiece during loading and unloading, then rotates it down and applies clamping force when air pressure is applied. This style of actuator is commonly found in automotive body-in-white assembly jigs, CNC machining fixtures, semiconductor handling equipment, and general industrial automation workcells. The auto-switch mounting grooves allow SMC D-series reed or solid-state sensors to be mounted directly on the cylinder for position feedback to a PLC.
