SMC MKB20-20LZ Pneumatic Rotary Clamp Cylinder 20mm Bore CCW w/ Auto-Switch
The SMC MKB20-20LZ is a compact pneumatic rotary clamp cylinder from SMC Corporation's MKB series. It combines linear stroke motion with rotary clamping action in a single unit, extending and rotating to clamp a workpiece, then reversing the sequence to release — all via compressed air. This unit has a 20mm bore, 20mm stroke, and rotates counterclockwise during the clamping stroke.
Specifications & What's Included
- Model: SMC MKB20-20LZ
- Series: SMC MKB (Rotary Clamp Cylinder)
- Bore Size: 20mm
- Stroke Length: 20mm
- Rotation Direction: Counterclockwise (CCW) during clamping stroke
- Actuation: Pneumatic (double-acting)
- Auto-Switch Mounting: Yes — grooves present for SMC auto-switch sensors
- Auto-switch wiring leads attached (multi-conductor, white connector)
- Inline push-in pneumatic fittings installed on ports
- Rod end: hex adjustment nut present
- Country of Manufacture: Japan
Applications
SMC MKB series rotary clamp cylinders are widely used in industrial automation and manufacturing equipment where a workpiece must be clamped securely before a machining, assembly, or inspection operation takes place. The combined linear-and-rotate motion — sometimes called swing-and-clamp — positions the clamp arm clear of the work zone when open, then sweeps in and presses down to hold the part when actuated. This keeps the clamping arm out of the way during loading and unloading, which is important on automated fixtures, jigs, and transfer lines. The MKB20 is a small-bore variant suited for compact fixtures on CNC machining centers, robotic assembly cells, pick-and-place tooling, and precision positioning fixtures. SMC is one of the world's largest pneumatic component manufacturers, and MKB series cylinders have been a standard choice in Japanese and global automotive and electronics manufacturing environments since the 1990s. The auto-switch compatibility allows integration with PLC-based control systems for position feedback without additional external sensors.
This SMC MKB20-20LZ Pneumatic Rotary Clamp Cylinder has been inspected and appears to be in good used condition. It was pulled from a working environment where it was in active service. The unit shows normal signs of use — the cylinder body and rod show light surface wear and handling marks consistent with industrial service, as visible in the photos. The attached auto-switch wiring leads and inline push-in pneumatic fittings are present. We did not perform pneumatic actuation testing at our facility. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
