Description
Sense SM3 Home Energy Monitor with Solar Sensors 120VAC Wi-Fi 2.4GHz New
The Sense SM3 is a whole-home energy monitoring device that installs inside your electrical panel to measure real-time current and voltage on both phases of your 120VAC service mains. It connects to your home Wi-Fi network and delivers live and historical energy data to the Sense app on your smartphone. This kit includes the Sense Solar add-on sensors, enabling simultaneous monitoring of both your home's overall consumption and your solar panel system's production output.
Specifications & What's Included
- Model: Sense SM3
- Monitor input compatibility: 120VAC (90V–130V), dual-phase service mains
- Monitor power supply input: 90–240V AC, 50/60Hz, 0.1A
- Wireless: Wi-Fi 2.4 GHz 802.11b/g/n
- Monitor dimensions: 137mm × 66mm × 32mm
- Certifications: ETL/Intertek (file 5002148), UL and IEC safety standards; FCC ID VPYLB1DX
- Assembled in Mexico
- Current Sensor Specs (Model CT5L):
- Rating: CAT IV 250V, 200A max
- Cable length: 46 inches
- Inside diameter: 0.95 inches
- Compatible with uninsulated conductors; UL2808 compliant
- Operating temperature: 32°F – 154.4°F (0°C – 68°C)
- What's Included:
- Sense SM3 monitor unit
- 2 main power current sensors (CT5L clamp-on)
- 2 solar current sensors (CT5L clamp-on)
- Power cable
- Antenna assembly (SMA connector)
- Solar monitoring sensor cables (in sealed bags)
- Documentation / quick-start guide
Applications
The Sense SM3 is designed for homeowners who want real-time visibility into their household electricity use and solar generation. Once the current sensors are clamped onto the service mains inside the breaker panel, the monitor tracks whole-home consumption continuously and sends the data to the Sense cloud platform via Wi-Fi. The included solar sensors clamp onto the output conductors from your solar inverter, allowing the app to display real-time solar production alongside consumption and calculate net usage. The platform stores historical data by day, week, month, year, and billing cycle — useful for understanding usage patterns, sizing battery storage, or verifying solar system output. The Sense monitor uses machine-learning algorithms to identify individual appliances over time based on their electrical signatures, providing per-device energy breakdowns without requiring smart plugs on every outlet. It is compatible with standard North American 120/240VAC split-phase residential panels.
This Sense SM3 Home Energy Monitor with Solar Sensors is new and unused. The kit ships factory-sealed in the original Sense box. For photography purposes, we opened one sample box to show the contents — the box you receive will be sealed. The complete kit includes the Sense monitor, 4 current sensors (2 main power + 2 solar), power cable, antenna assembly, and solar monitoring cables. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Sense |
Model: |
SM3 |
MPN: |
SM3 |
Type: |
Home Energy Monitoring Device |
SKU: |
52859 |
Seller Notes: |
Complete sealed kit: monitor, 4 current sensors (2 main + 2 solar), power cable, antenna assembly |
Country/Region of Manufacture: |
Mexico |
Form Factor: |
Panel-Mount / Compact Module |
Power Requirements: |
90-240V AC, 50/60Hz, 0.1A |
Compatibility: |
120VAC (90V-130V), dual-phase service mains |
Wireless Connectivity: |
Wi-Fi 2.4 GHz 802.11b/g/n |
Current Sensor Rating: |
CAT IV 250V, 200A max |
Current Sensor Cable Length: |
46 inches |
Current Sensor Inside Diameter: |
0.95 inches |
Number of Current Sensors Included: |
4 (2 main power + 2 solar) |
Monitor Dimensions: |
137mm x 66mm x 32mm |
Certifications: |
ETL/Intertek certified, UL and IEC safety standards, FCC ID VPYLB1DX |
Solar Monitoring: |
Yes — real-time and historical (day/week/month/year/billing cycle) |
Intertek File Number: |
5002148 |
FCC ID: |
VPYLB1DX / 772C-LB1DX |
Condition Notes: |
Sense SM3 Home Energy Monitor with Solar Sensors — new, factory-sealed kit. One box was opened for photos only; the unit you receive ships sealed and complete with all sensors and accessories. |
