Description
Robotic Rotation Cylinder 230mm Pick-n-Place 560mm Positioning Arm THK LTR20
Inline rotary cylinder with 560mm extended positioning arm for pick-and-place robotic systems. Used as an actuator and positioning component in automated material handling and assembly equipment.
Specifications & What's Included
- Model: LTR20 (THK linear guide component)
- Cylinder length: 230 mm
- Arm shaft length: 560 mm
- Shaft diameter: 20 mm (main), 18 mm x 30 mm at mounting end
- Mounting flange: 110 mm diameter, 15 mm thickness, four 9 mm holes
- Body diameter: 72 mm
- End effector attachment: 11 mm internal radius, 30 mm deep
- Materials: Stainless steel and aluminum body construction
Applications
This cylinder type is used in pick-and-place robotic systems for semiconductor wafer handling, component placement in SMT (surface mount technology) lines, and automated assembly operations. Typically integrated into gantry-based or articulated robotic platforms where rotational positioning and extended reach are required. Common in electronics manufacturing and precision industrial automation.
Condition: Used
This Robotic Rotation Cylinder with 560mm Positioning Arm has been inspected and is in good used condition. It was pulled from a working pick-n-place system where it was in active use. The stainless steel cylinder body and shaft show normal surface wear consistent with production use. The mounting flange, end effector bracket, and THK LTR20 shaft bushing assembly all appear intact and undamaged. Some grease residue and general industrial soiling is visible on the bearing face and shaft area, as seen in the photos. Please view our photo set and contact us if you have any questions.
This Robotic Rotation Cylinder with 560mm Positioning Arm has been inspected and is in good used condition. It was pulled from a working pick-n-place system where it was in active use. The stainless steel cylinder body and shaft show normal surface wear consistent with production use. The mounting flange, end effector bracket, and THK LTR20 shaft bushing assembly all appear intact and undamaged. Some grease residue and general industrial soiling is visible on the bearing face and shaft area, as seen in the photos. Please view our photo set and contact us if you have any questions.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Unbranded |
Model: |
LTR20 |
MPN: |
LTR20 |
Type: |
Robotic Rotation Cylinder / Pick-n-Place Actuator |
SKU: |
48702 |
Seller Notes: |
Rotation cylinder and 560mm positioning arm included as shown |
Cylinder Length: |
230 mm |
Shaft / Arm Length: |
560 mm |
Mounting Flange Diameter: |
110 mm |
Mounting Flange Thickness: |
15 mm |
Mounting Hole Size: |
9 mm (4 holes on flange) |
Body Diameter (above flange): |
72 mm |
Body Diameter (below flange): |
72 mm |
Overall Cylinder Dimensions: |
230 mm L x 110 mm x 100 mm |
Shaft Diameter: |
20 mm (main arm shaft) |
Shaft Mounting End: |
18 mm diameter x 30 mm long |
End Effector / Hand Attachment: |
11 mm internal radius, 30 mm deep |
Linear Guide Component: |
THK LTR20 |
Application: |
Pick-n-Place Robotic System, Semiconductor Automation |
Compatible With: |
Pick-n-Place SMT / semiconductor handling systems |
Material: |
Stainless steel and aluminum body construction |
Form Factor: |
Inline rotary cylinder with extending shaft arm |
Condition Notes: |
This Robotic Rotation Cylinder with 560mm Positioning Arm was pulled from a working pick-n-place system and is in good used condition. Normal wear visible on body and shaft. Flange, bracket, and THK LTR20 bushing intact. |
