KMW Microwave 200580-001 Rev 1 RF Cable N-Type Male to SMA Right Angle 17in

KMW Microwave 200580-001 Rev 1 RF Cable N-Type Male to SMA Right Angle 17in

This KMW Microwave 200580-001 Rev 1 is a flexible RF coaxial cable assembly approximately 17 inches in length, terminated with an N-type male connector on one end and an SMA right-angle male connector on the other. The cable features a braided stainless steel outer jacket over a blue-sleeved inner conductor, with the part number and revision printed directly on the sleeve for easy identification.

Specifications & What's Included

• Manufacturer: KMW Microwave
• Part Number: 200580-001
• Revision: Rev 1
• Cable Length: Approximately 17 inches
• Connector End 1: N-Type Male (straight)
• Connector End 2: SMA Male, Right Angle
• Cable Construction: Braided stainless steel outer jacket with blue inner sleeve
• Application: RF / microwave signal interconnect
• Cable only — no additional accessories included

Applications

N-type to SMA coaxial cable assemblies are standard interconnects in RF and microwave systems, used to route signals between instruments, components, and antennas in test benches, base station equipment, spectrum analyzers, signal generators, and microwave subsystems. The N-type connector is a common interface on instruments and bulkhead feedthroughs rated for use up to several GHz, while the SMA right-angle configuration allows connection in space-constrained enclosures or on PCB-mounted SMA ports. Cables of this construction — flexible braided jacket with precision machined connectors — are widely used in telecom, aerospace, and RF lab environments where a reliable, low-loss coaxial link is needed between components at microwave frequencies.
