J Schneider

J. Schneider NGDS 2425-930818T3 AC-DC Transformer 220-480V PRI 24VDC 25A 600W

(No reviews yet) Write a Review
SKU:
45961
MPN:
NGDS 2425-930818T3
Condition:
Used
Availability:
Usually ships within 1-2 business days.
Weight:
26.00 LBS
Shipping:
Calculated at Checkout
  • J. Schneider NGDS 2425-930818T3 AC-DC transformer front-left view showing large heatsink, terminal blocks, and transformer core on DIN-rail base
  • J. Schneider NGDS 2425-930818T3 transformer rear-right view showing large black heatsink fins, capacitor, and wiring connectors
  • J. Schneider NGDS 2425-930818T3 rating plate closeup showing model number, VDE 0550 rating, 200-480V primary, 24VDC 25A secondary, 600W
  • Weber Protection T13-211 18A switch detail showing broken mount area and label markings on the J. Schneider transformer assembly
$140.00
Was: $275.00
Current Stock: 1

Sold Out

Description

J. Schneider NGDS 2425-930818T3 AC-DC Transformer 220-480V PRI 24VDC 25A 600W

AC-DC rectifier transformer manufactured by J. Schneider Elektrotechnik. Converts single-phase AC input to 24V DC output at 25A continuous current, rated 600W.

Specifications & What's Included

  • Primary: 200–240V AC or 380–480V AC, 50/60 Hz
  • Secondary: 24V DC, 25A output
  • Power rating: 600W
  • VDE 0550 certified, CE marked
  • DIN-rail / panel mount form factor
  • Includes three Weber Protection T13-211 18A switches (one with broken mount)

Applications

Industrial rectifier transformers of this type supply regulated DC power to control circuits, switchgear, and telecom equipment. The 24V DC output is standard for PLC logic inputs, solenoid coils, and signal conditioning in factory automation and telecommunications infrastructure. Dual-voltage primary enables use across North American and European power grids.

Condition: Used
This J. Schneider NGDS 2425-930818T3 AC-DC transformer has been inspected and is in used condition. The unit is complete and intact overall; however, one of the three Weber Protection switches has a broken mount — this is visible in our photos. The transformer core, heatsink assembly, and terminal wiring appear intact. Please review our full photo set carefully before purchasing, and contact us with any questions.
View AllClose

Warranty Information

We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose

Additional Information

Brand:
J. Schneider Elektrotechnik
Model:
NGDS 2425-930818T3
MPN:
NGDS 2425-930818T3
Secondary Model:
190140/1
Type:
AC-DC Rectifier Transformer
SKU:
45961
Primary Voltage:
200-240V AC / 380-480V AC
Secondary Voltage:
24V DC
Secondary Current:
25A
Power Rating:
600W
Primary Current:
3.15A (200-240V) / 2.0A (380-480V)
Frequency:
50/60 Hz
Phase:
Single Phase
Certifications:
VDE 0550, CE
Transformer Standard:
VDE 0550 ta40/B50/60Hz
Output Type:
DC
Includes:
Weber Protection T13-211 18A switch (3 units, one mount broken)
Form Factor:
Panel / DIN-Rail Mount
Condition:
Used – Inspected; broken mount on one Weber switch
Seller Notes:
One of the three Weber Protection switch mounts is broken; see photos
Country/Region of Manufacture:
Germany
Manufacturer Location:
J. Schneider Elektrotechnik GmbH, 77652 Offenburg
Condition Notes:
J. Schneider NGDS 2425-930818T3 transformer, used. One of three Weber Protection switch mounts is broken — see photos. Otherwise complete. Contact us with questions.
View AllClose
