Description
Intel Pentium P200 200MHz CPU SY044 FV80502200 Socket 7 Processor
The Intel Pentium P200 (SY044 / FV80502200) is a 200 MHz Socket 7 desktop processor based on Intel's P54C microarchitecture. Running at 200 MHz on a 66 MHz front-side bus with a 3x multiplier, it was the fastest standard (non-MMX) Pentium Intel produced before the Pentium MMX line took over. This chip uses a 3.3V core and features a 16 KB split L1 cache (8 KB instruction, 8 KB data) in a ceramic SPGA package with gold-plated Socket 7 pins.
Specifications & What's Included
- Brand: Intel
- Processor Family: Pentium (P54C)
- sSpec Number: SY044
- Part Number (OPN): FV80502200
- Clock Speed: 200 MHz
- Front-Side Bus (FSB): 66 MHz
- Bus Multiplier: 3x
- Socket: Socket 7 (SPGA, 296-pin)
- L1 Cache: 16 KB (8 KB instruction + 8 KB data)
- Core Voltage: 3.3V
- Process Node: 0.35 micron CMOS
- TDP: ~15.5W
- Package: Ceramic SPGA with gold Socket 7 pins
- Stepping: A4 (visible on chip)
- Date Code: Q2 1995
- Included: CPU only — no heatsink or fan
Applications
The Pentium P200 dates from 1995–1996, the peak era of the original Pentium's dominance in desktop PCs. Socket 7 was the standard desktop CPU socket of the time, supported by motherboards from Intel, ASUS, Gigabyte, MSI, and many others. At 200 MHz it was the top-of-the-line Pentium before the Pentium MMX launched in early 1997 with its dedicated multimedia instruction set. Today the P200 is sought after for restoring period-correct mid-to-late-1990s desktop PCs and DOS/Windows 95/98 retro gaming builds, where its non-MMX Pentium architecture maintains compatibility with software and games from that era. It is also compatible with any Socket 7 motherboard that supports 3.3V CPUs at a 66 MHz FSB.
This Intel Pentium P200 200MHz processor (SY044 / FV80502200) has been tested at our facility and is in good working condition. The gold Socket 7 pins are intact and show no bending or damage. The top of the processor shows some dried thermal compound residue on the integrated heat spreader, which is normal and expected on a used CPU. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Intel |
Model: |
Pentium P200 |
MPN: |
FV80502200 |
Secondary Model: |
SY044 |
SKU: |
41710 |
Type: |
Desktop Processor / CPU |
Processor Speed: |
200 MHz |
Socket Type: |
Socket 7 |
Number of Cores: |
1 |
Bus Speed: |
66 MHz |
L1 Cache: |
16 KB (8 KB instruction + 8 KB data) |
Process Technology: |
0.35 micron CMOS |
Thermal Design Power: |
15.5W |
Voltage: |
3.3V |
Architecture: |
P54C (Pentium) |
Country/Region of Manufacture: |
Malaysia |
Form Factor: |
SPGA (Staggered Pin Grid Array) |
Compatible With: |
Socket 7 motherboards (Intel, ASUS, Gigabyte, MSI) |
Seller Notes: |
CPU only; no heatsink or fan included. |
Condition Notes: |
This Intel Pentium P200 SY044 / FV80502200 processor has been tested and is in good working condition. Socket 7 pins are intact. Dried thermal compound residue visible on IHS — normal for a used CPU. |
