Description
Intel EtherExpress 16 ISA LAN Adapter 305896-004 BNC Coax DB15 AUI 10Mbps
16-bit ISA Ethernet network adapter card for legacy desktop computers. Provides 10 Mbps network connectivity via BNC coaxial or DB15 AUI connectors using the Intel 82586 chipset.
Specifications & What's Included
- Model: Intel EtherExpress 16 (MPN 305896-004)
- Bus Interface: 16-bit ISA
- Network Speed: 10 Mbps Ethernet (10BASE2, 10BASE5)
- Connectors: BNC coax and DB15 AUI
- Chipset: Intel 82586; Controller: Intel 82501
- Form Factor: Half-length ISA card
- Card only; no drivers or accessories included
Applications
This adapter was used to network IBM PC/AT and compatible ISA-bus desktop computers from the 1980s-1990s. It supported MS-DOS, Windows 3.x, Windows for Workgroups, OS/2, and Novell NetWare environments. Typical installations included office workstations, laboratory equipment, and industrial control systems requiring network connectivity on legacy 10BASE2 thin Ethernet or 10BASE5 thick Ethernet coaxial cable runs.
Condition: Used
This Intel EtherExpress 16 ISA LAN Adapter (305896-004) has been inspected and appears to be in good used condition. The card was pulled from a working environment and shows normal light wear consistent with previous installation. The PCB is clean with no visible corrosion, broken traces, or damaged components. The BNC coax connector and DB15 AUI port on the bracket are intact. The ISA edge connector looks clean and undamaged. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
This Intel EtherExpress 16 ISA LAN Adapter (305896-004) has been inspected and appears to be in good used condition. The card was pulled from a working environment and shows normal light wear consistent with previous installation. The PCB is clean with no visible corrosion, broken traces, or damaged components. The BNC coax connector and DB15 AUI port on the bracket are intact. The ISA edge connector looks clean and undamaged. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Intel |
Model: |
EtherExpress 16 |
MPN: |
305896-004 |
Secondary Model: |
PB305898-002 |
Type: |
ISA Ethernet LAN Adapter Card |
SKU: |
10221 |
Bus Interface: |
16-bit ISA |
Network Speed: |
10 Mbps |
Network Standard: |
Ethernet (10BASE2, 10BASE5) |
Connector Type: |
BNC (Coax), DB15 AUI |
Chipset: |
Intel 82586 |
Controller: |
Intel 82501 (Serial Interface) |
Oscillator: |
Kyocera KXO-HC1-TS 20.0000MHz |
FCC ID: |
EJMPCE0PCLA8110A |
Form Factor: |
Half-Length ISA Card |
Power Requirements: |
12V to 9V (Valor PM6042 transformer) |
Compatible With: |
IBM PC/AT, ISA-bus desktop PCs, DOS/Windows 3.x |
Compatible With 2: |
MS-DOS, Windows for Workgroups, OS/2, Novell NetWare |
Condition: |
Used – Inspected, Pulled from Working Environment |
Seller Notes: |
Card only; no drivers or accessories included. |
Country/Region of Manufacture: |
USA |
Review Status: |
Auto-Approved (needs review) 2026-07-03 |
Condition Notes: |
Intel EtherExpress 16 ISA LAN Adapter 305896-004. Pulled from a working environment; inspected and in good used condition. PCB clean, BNC and DB15 AUI connectors intact, ISA edge connector clean. No visible damage. |
