Description
IBM DHEA-38451 8.45GB 3.5" IDE Hard Drive 00K0395 Dell Desktop HDD
The IBM DHEA-38451 is a 3.5-inch internal IDE hard disk drive with 8.45 GB of storage capacity. Manufactured in January 1998 by IBM Storage Products (Thailand) Ltd., this drive uses the standard 40-pin Parallel ATA (IDE/PATA) interface and is formatted for use in desktop PC systems. It was supplied as an OEM drive to Dell and carries both the IBM part number 00K0395 and the Dell DP/N 00056669.
Specifications & What's Included
- Manufacturer: IBM Storage Products (Thailand) Ltd.
- Model: DHEA-38451 (E182115 S)
- Part Number (P/N): 00K0395
- MLC: E67648
- Dell DP/N: 00056669-12561-81J-2B5N
- Capacity: 8.45 GB (8450 MB)
- Form Factor: 3.5" internal
- Interface: IDE (40-pin Parallel ATA / PATA)
- Cylinders: 16,383
- Read/Write Heads: 16
- Sectors per Track: 63
- Power: 5V DC at 320 mA; 12V DC at 260 mA
- Manufacture Date: January 1998
- Connectors: 40-pin IDE data connector; 4-pin Molex power connector
- Included: Drive only — no cables or mounting hardware
Applications
The DHEA-38451 is a late-1990s generation desktop hard drive from IBM's Deskstar product line, designed for use in IBM-compatible PC desktop systems of that era. Drives of this type were standard storage in Pentium II and early Pentium III desktop computers running Windows 95, Windows 98, and Windows NT 4.0. This drive was specifically supplied as an OEM unit to Dell for integration into Dell desktop systems of the same period. Today, drives like this see continued use in legacy computer restoration projects, vintage PC builds, and period-correct system repairs where IDE interface drives are required. The 40-pin PATA interface was the dominant desktop storage standard through the late 1990s and into the mid-2000s before SATA became the mainstream replacement.
This IBM DHEA-38451 8.45GB 3.5" IDE hard drive has been inspected, cleaned, and tested at our facility and is in very good working condition. The drive powers up and functions correctly. The label and casing show normal light wear consistent with prior use, but there is no damage to the connector pins or housing. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
IBM |
Model: |
DHEA-38451 |
MPN: |
00K0395 |
Secondary Model: |
E182115 S |
Type: |
Internal Hard Disk Drive (HDD) |
Storage Capacity: |
8.45 GB |
Interface: |
IDE (ATA / PATA) |
Form Factor: |
3.5" |
Bytes per Sector: |
63 SEC/T |
Cylinders: |
16383 |
Read/Write Heads: |
16 |
Power Requirements: |
5V 320mA, 12V 260mA DC |
Country/Region of Manufacture: |
Thailand |
MLC: |
E67648 |
DP/N: |
00056669-12561-81J-2B5N |
Manufacture Date: |
JAN-98 |
Compatible With: |
Dell Desktop Systems (OEM) |
Condition: |
Used – Inspected and Tested |
SKU: |
20438 |
Seller Notes: |
Drive only; no cables or accessories included. |
Condition Notes: |
IBM DHEA-38451 8.45GB IDE hard drive. Inspected, cleaned, and tested — in very good working condition. Normal light wear on label and casing; connector pins intact. Drive powers up and functions correctly. |
