HP 8746B S-Parameter Test Set 0.5-12.4 GHz Agilent w/ 8411A Converter
The HP (Hewlett-Packard) / Agilent 8746B is a microwave S-Parameter Test Set designed to measure all four S-parameters (S11,...
51647
- SKU:
- 51647
- Availability:
- Usually ships within 1–2 business days.
- Weight:
- 46.00 LBS
- Brand:
- HP (Hewlett-Packard) / Agilent
- Model:
- 8746B
- MPN:
- 8746B
- Type:
- S-Parameter Test Set
- SKU:
- 51647
- Frequency Range:
- 0.5 to 12.4 GHz
- Directivity:
- ≥30 dB (0.5–4 GHz); ≥26 dB (4–12.4 GHz)
- Incident Signal Attenuation:
- 0 to 70 dB (selectable)
- S-Parameters Measured:
- S11, S12, S21, S22
- Included Accessories 1:
- 8411A Harmonic Frequency Converter (0.1–12.4 GHz)
- Included Accessories 2:
- 8746B-H25 Reference Line
- Internal Bias:
- Yes — for two-port active device characterization
- Reference Plane Extension:
- Calibrated line stretcher (cm scale, front panel)
- Port Configuration:
- Port 1, Port 2 — Type-N connectors
- Form Factor:
- Rackmount / Benchtop
- Dimensions:
- 19" W x 18" D x 5.25" H
- Remote Interface:
- Remote Input connector (rear panel)
- Seller Notes:
- Includes 8411A Harmonic Frequency Converter and 8746B-H25 Reference Line
- Country/Region of Manufacture:
- United States
- Condition:
- Used – Powered On, Sold As-Is
- Condition Notes:
- HP Agilent 8746B S-Parameter Test Set powered on at our facility and appeared to function normally. Full RF calibration verification was not performed. Sold as-is. Includes 8411A Converter and 8746B-H25 Reference Line. Contact us with questions.
