Description
HP 1652B 1653B 01652-90905 Logic Analyzers Service Manual Feb 1990
This is the original Hewlett-Packard service manual for the HP 1652B and HP 1653B Logic Analyzers, publication part number 01652-90905 (microfiche part number 01652-90805), printed in February 1990. It covers instruments with serial number prefixes 2941A, 2942A, 3011A, and 3012A and above, and is presented in a white ring binder with color-coded tabbed section dividers.
Specifications & What's Included
- Publication Part Number: 01652-90905
- Microfiche Part Number: 01652-90805
- Print Date: February 1990
- Instruments Covered: HP 1652B and HP 1653B Logic Analyzers
- Serial Numbers Covered: Prefixes 2941A, 2942A, 3011A, 3012A and above
- Format: Printed pages in white ring binder with color-coded tabbed dividers
- Language: English
- Publisher: Hewlett-Packard Company, Colorado Division (Colorado Springs, CO)
- Sections included:
- Section 1: General Information (product description, specifications, accessories)
- Section 2: Installation (safety, HP-IB interfacing, power requirements)
- Section 3: Performance Tests (self tests, clock/qualifier/data input tests, threshold, oscilloscope, bandwidth, trigger sensitivity)
- Section 4: Adjustments and Calibration (power supply, CRT monitor, focus, horizontal/vertical, software calibration)
- Section 5: Replaceable Parts (abbreviations, exchange assemblies, ordering information)
- Section 6A: Theory of Operation (block-level, CPU, oscilloscope, logic analyzer, acquisition, memory, HP-IB)
- Section 6B: Self Tests (power-up, selectable, data acquisition, RS-232-C, BNC, keyboard)
- Section 6C: Troubleshooting (isolation flowcharts, power supply voltages, CRT, keyboard, disk drive, auxiliary power)
- Section 6D: Assembly Removal and Replacement (rear panel, disk drive, attenuators, power supply, oscilloscope, keyboard, fan, main assembly, CRT monitor, feet/tilt stand)
Applications
The HP 1652B and 1653B are combination logic analyzer and oscilloscope instruments introduced by Hewlett-Packard in the late 1980s. They provide both state and timing analysis for digital logic circuits alongside oscilloscope channel capability, making them widely used for digital system development, validation, and troubleshooting in electronics labs and field service environments. This service manual is the essential reference for technicians performing calibration, performance verification, or repair on these instruments. It covers the full scope of bench servicing — from self-test procedures and performance measurements through component-level theory of operation, adjustment procedures, and assembly removal and replacement. Engineers and technicians maintaining legacy HP test equipment, or acquiring these analyzers for ongoing lab use, rely on this manual to keep the instruments in calibrated, working condition.
This HP 1652B/1653B Logic Analyzers Service Manual (part no. 01652-90905) is in good used condition overall. All pages are present and legible, and the tabbed section dividers are intact. The rear binding of the binder is coming loose at the seam — the pages and content are unaffected, but buyers should be aware of this cosmetic defect. Normal shelf wear is visible on the cover. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
HP |
Model: |
1652B/1653B |
MPN: |
01652-90905 |
Secondary Model: |
01652-90805 |
SKU: |
49373 |
Type: |
Service Manual |
Document Type: |
Service Manual |
For Make/Model: |
HP 1652B / HP 1653B Logic Analyzers |
Publication Part Number: |
01652-90905 |
Microfiche Part Number: |
01652-90805 |
Print Date: |
February 1990 |
Serial Numbers Covered: |
Prefixed 2941A, 2942A, 3011A, 3012A and above |
Language: |
English |
Format: |
Printed / Ring Binder |
Country/Region of Manufacture: |
United States |
Seller Notes: |
Manual only — binder, all pages, and tabbed dividers included. |
Condition Notes: |
HP 1652B/1653B Logic Analyzers Service Manual, P/N 01652-90905. Good used condition — all pages present and legible, tabbed dividers intact. Rear binder seam is coming loose. Normal shelf wear on cover. |
