HP 16500A Logic Analysis System Mainframe Service Manual 16500-90901 Sep 1987
This is the original Hewlett-Packard service manual for the HP 16500A Logic Analysis System Mainframe. HP part number 16500-90901, printed September 1987, this manual applies directly to instruments with serial numbers prefixed 2650A. It is a comprehensive bound reference covering installation, performance tests, adjustments, replaceable parts, and full service/repair procedures for the 16500A mainframe.
Specifications & What's Included
- Document Type: Service Manual (printed, bound)
- HP Publication / Part Number: 16500-90901
- Microfiche Part Number: 16500-90801 (microfiche not confirmed included)
- Print Date: September 1987
- Applies To: HP 16500A Logic Analysis System Mainframe, serial prefix 2650A and above
- Language: English
- Sections include: General Information, Installation, Performance Tests, Adjustments, Replaceable Parts, and Service
- Service section covers: system overview, power-up tests, microprocessor board theory, mainframe test system, troubleshooting, and board/module replacement procedures
- Includes List of Tables, List of Illustrations, and replaceable parts list with exchange assemblies
- Interfaces covered: HP-IB (GPIB), RS-232-C, touchscreen, mouse
Applications
The HP 16500A is a modular logic analysis system mainframe introduced by Hewlett-Packard in the mid-1980s. It serves as the chassis and controller for a family of interchangeable measurement modules — state analyzers, timing analyzers, and oscilloscope modules — making it a versatile platform for digital hardware development and verification. This service manual is the primary reference for technicians performing maintenance, board-level repair, or calibration on a 16500A mainframe. It is used by engineers maintaining vintage HP logic analyzers still in operation in legacy production and R&D environments, as well as collectors and repair specialists working on classic HP test equipment. The 16500A and its successor the 16500B were widely used through the late 1980s and 1990s in electronics design labs, semiconductor development, and embedded systems work. HP-IB (the HP implementation of IEEE-488 / GPIB) and RS-232-C interface coverage in this manual reflects the standard instrument connectivity of that era. Technicians maintaining or restoring a 16500A mainframe will find the replaceable parts list, troubleshooting flow charts, and board replacement procedures in this manual essential references.
This HP 16500A Logic Analysis System Mainframe Service Manual (P/N 16500-90901) has been inspected and is in good used condition. The cover shows normal shelf wear — consistent with a working-copy manual from the late 1980s — and the spine is intact. All pages appear present and legible based on our inspection. This manual covers instruments with serial numbers prefixed 2650A and was printed in September 1987. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
Hewlett-Packard |
Model: |
16500A |
MPN: |
16500-90901 |
Secondary Model: |
16500-90801 |
Type: |
Service Manual |
SKU: |
48837 |
Document Type: |
Service Manual |
Publication Number: |
16500-90901 |
Microfiche Part Number: |
16500-90801 |
Print Date: |
September 1987 |
Serial Number Range: |
Instruments with serial prefix 2650A |
For Use With / Compatible: |
HP 16500A Logic Analysis System Mainframe |
Language: |
English |
Format: |
Printed / Bound |
Country/Region of Manufacture: |
United States |
Condition: |
Used – Inspected and in Good Condition |
Seller Notes: |
Includes printed bound service manual; microfiche not confirmed included |
Condition Notes: |
HP 16500A Logic Analysis System Service Manual (P/N 16500-90901) inspected and in good used condition. Cover shows normal shelf wear; spine intact; all pages present and legible. Printed September 1987, covers SN prefix 2650A. |
