Honeywell 1858 Visicorder Oscillograph Chart Recorder Rack Mount For Parts Repair
The Honeywell 1858 Visicorder is a multi-channel galvanometer-based oscillograph chart recorder designed for capturing dynamic waveforms on light-sensitive or direct-print paper. This unit powers on and responds to manual front-panel controls, but is missing its plug-in galvanometer modules and the paper cover, and is being sold AS-IS for parts or repair only. The rack-mount chassis, rear-panel connector array, and power system appear intact as shown in the photos.
Specifications & What's Included
- Make: Honeywell
- Model: 1858 Visicorder
- Type: Oscillograph / galvanometer chart recorder
- Form factor: Rack-mount chassis
- Recording method: Light-beam galvanometer (oscillograph) — records onto chart paper
- Plug-in module bays: Multiple bays visible on front panel — modules NOT included
- Rear panel: Two rows of galvanometer channel input connectors (blue, approximately 12 total visible)
- Rear panel: Signal input terminal block and power inlet present
- Front panel: Power switch, mode controls, and indicator lights present
- Paper cover/transport cover: NOT included (missing)
- Plug-in galvanometer modules: NOT included (missing)
- Powers on: Yes — unit powers up and responds to manual controls
- Sold AS-IS for parts or repair — no functionality guarantee as a complete recording system
Applications
The Honeywell Visicorder series was a widely used family of oscillograph recorders produced from the 1960s through the 1980s, designed for high-speed, multi-channel waveform recording in research, aerospace, defense, and industrial test environments. Visicorder instruments recorded signals from galvanometer elements onto ultraviolet-sensitive or thermal paper, allowing engineers to capture fast transient events — vibration, shock, pressure pulses, electrical waveforms — that strip-chart pen recorders could not follow. The 1858 model in particular was used in structural dynamics testing, flight test data acquisition, engine and powertrain research, and military qualification testing. Galvanometer plug-in modules were interchangeable, allowing the system to be configured for different frequency ranges and sensitivities per channel. Today, the 1858 chassis and its rear connector assemblies, power supplies, and individual galvanometer modules are sought after for restoration projects or as spare parts for other working Visicorder systems.
This Honeywell 1858 Visicorder chart recorder is being sold AS-IS for parts or repair. The unit does power on and responds to manual controls, but it is missing its plug-in galvanometer modules and the paper cover. Without the plug-in modules it cannot perform recording functions in its current state. The chassis and rear panel galvanometer connectors are present and intact as shown in the photos. The front panel shows the expected wear of a vintage rack-mount instrument — scuffing on the chassis and panel surfaces — and the rear panel connector rows appear complete. This item is offered for parts, salvage, or as a restoration project and is not guaranteed functional as a complete system. Please view our photo set and contact us if you have any questions.
