Description
Hipro HP-250ATXA6 235W ATX Desktop PC Power Supply 115V 230V Rev 01
This is a used ATX form factor power supply unit designed for desktop computers. It delivers up to 235W (250W max) across multiple voltage rails and supports both 115V and 230V AC input.
Specifications & What's Included
- Model: HP-250ATXA6 Rev 01
- Power Output: 235W (Max 250W)
- Input: 115V/230V AC, 50/60Hz
- Connectors: 20-pin ATX, 4-pin Molex, Berg (floppy)
- DC Rails: +5V (27A), +12V (9A), +3.3V (14A), ±5V/±12V auxiliary
- Cooling: 80mm internal fan
- Certifications: UL, CSA, CE, FCC
- Unit only; no additional accessories included
Applications
ATX power supplies of this class were used in desktop computers from the mid-1990s through early 2000s. This unit is compatible with ATX form factor systems and was commonly found in consumer-grade desktop PCs. It may be used for system restoration, legacy computer repair, or as a replacement component in compatible machines.
Please note: We may have multiple units of this item in stock. The unit you receive may vary slightly from the one shown in the photos. All units are functionally equivalent and inspected to the same standard.
This Hipro HP-250ATXA6 235W ATX desktop power supply has been inspected and appears to be in good used condition. The unit shows typical light cosmetic wear consistent with prior use. The specification label and QC test label on the unit are intact and legible. All output connectors — including the 20-pin ATX main connector, Molex peripheral leads, and Berg floppy connectors — appear present and undamaged. The rear panel IEC inlet, power switch, and voltage selector are present and show normal wear. This unit has not been bench-tested at our facility. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Hipro |
Model: |
HP-250ATXA6 |
MPN: |
HP-250ATXA6 |
SKU: |
18949 |
Condition: |
Used – Inspected |
Seller Notes: |
Unit only; no additional accessories included. |
Form Factor: |
ATX |
Power Output: |
235W (Max 250W) |
AC Input Voltage: |
115V / 230V AC |
AC Input Frequency: |
60/50Hz |
AC Input Current: |
115V: 6A; 230V: 3.5A |
DC Output +5V: |
27A |
DC Output +12V: |
9A |
DC Output -5V: |
0.5A |
DC Output -12V: |
0.5A |
DC Output +5VSB: |
1A |
DC Output +3.3V: |
14A |
Hardware Revision: |
Rev 01 |
Connector Types: |
20-pin ATX, 4-pin Molex, Berg (floppy) |
Compatible With: |
ATX form factor desktop computers |
Country of Manufacture: |
China |
Certifications: |
UL, CSA, CE, FCC |
Cooling: |
80mm internal cooling fan |
Condition Notes: |
This Hipro HP-250ATXA6 235W ATX power supply is in good used condition with light cosmetic wear. All connectors appear intact. Not bench-tested at our facility. Please view photos and contact us with any questions. |
