HP Hewlett-Packard J2593A-60001 JetDirect EX Plus3 3-Port Parallel Print Server

HP Hewlett-Packard J2593A-60001 JetDirect EX Plus3 3-Port Parallel Print Server

The HP JetDirect EX Plus3 (J2593A) is an external network print server that connects up to three parallel-port printers directly to an Ethernet network, allowing any networked computer to send print jobs without a dedicated print PC. It supports both 10Base-T (RJ-45) and 10Base-2 (BNC coax) Ethernet connections, and connects to printers via standard Centronics/IEEE-1284 parallel interfaces. The AC power adapter is included.

Specifications & What's Included

• Model: J2593A / Part Number: J2593-60001
• Type: External Network Print Server
• Printer Ports: 3 × Centronics parallel (IEEE-1284) — Port 1 doubles as config page port
• Network Interfaces: 10Base-T (RJ-45) and 10Base-2 (BNC coax)
• Network Speed: 10 Mbps Ethernet
• Power: 13 VDC, 625mA via external AC adapter
• AC adapter: Included (not photographed)
• Country of Manufacture: Singapore
• Compatible network OS: Novell NetWare, Microsoft Windows NT/9x/3.x, IBM OS/2, Sun OS, HP-UX, IBM AIX, Artisoft LANtastic, Apple EtherTalk
• Compatible printers: HP LaserJet, HP OfficeJet, HP DeskJet, HP Professional Series, HP DeskJet, and HP DesignJet series

Applications

The HP JetDirect EX Plus3 was designed to let businesses and workgroups share parallel-port printers across an Ethernet LAN without tying a workstation to print-server duty. Introduced in the mid-to-late 1990s, JetDirect external print servers were a standard fixture in HP-centric office and enterprise environments of that era — connecting HP LaserJets and other parallel-port printers to both TCP/IP and Novell IPX networks. The three-port design allowed a single unit to serve an entire small print room. Today these units continue to be used to keep older parallel-port laser printers alive on modern networks, particularly in legacy environments, schools, and small offices that still operate HP LaserJet hardware from the same generation.
