Description
Fuji Electric SC-E3/G SE65AG Magnetic Contactor 65A 3-Pole 24VDC Coil
The Fuji Electric SC-E3/G is a 3-pole IEC-style motor control magnetic contactor rated at 65A, designed for non-reversing motor starter applications in industrial control panels. This unit carries part number SE65AG and features a 24V DC operating coil with A1/A2 terminals. It is DIN rail mountable and bears UL, CE, and TUV Rheinland certifications.
Specifications & What's Included
- Manufacturer: Fuji Electric FA
- Model: SC-E3/G
- Part Number: SE65AG
- Type: Non-reversing 3-pole magnetic motor contactor
- Continuous Current Rating: 65A (100A per UL label)
- Coil Voltage: 24V DC (terminals A1 / A2)
- Frame Width: 67mm
- Poles: 3 (Line: 1L1, 3L2, 5L3 / Load: 2T1, 4T2, 6T3)
- Voltage Range: 110–120V / 200–240V / 440–480V / 550–600V AC
- HP Rating (1-Phase): 5 HP @ 110–120V; 15 HP @ 200–240V
- HP Rating (3-Phase): 20 HP @ 200–240V; 25 HP @ 440–480V; 50 HP @ 550–600V
- Short Circuit Rating: 5kA, 600V
- Max Fuse: K5 / RK5, 125A
- Max Circuit Breaker: 125A
- Wire Rating: 75°C Copper wire only
- UL Listed: IND. CONT. EQ. 253C
- TUV Rheinland certified; CE marked
- Mounting: DIN rail / panel mount
- Country of Manufacture: China
- Includes: Contactor only — no auxiliary contacts, cables, or mounting accessories
Applications
IEC magnetic contactors like the Fuji Electric SC-E3/G are a standard component in industrial motor control centers (MCCs), motor starter assemblies, and control panels worldwide. They are used to switch three-phase AC motor loads on and off under control of a low-voltage coil signal — in this case, 24V DC, which is the standard control voltage in many PLC-driven automation systems. The SC-E3 series is widely used in manufacturing, packaging, HVAC, pumping, conveyor, and machine tool applications where reliable motor switching is required. At 65A / up to 50 HP (3-phase at 550–600V), this contactor is sized for medium-duty motor loads and fits within Fuji Electric's SC-E series line of IEC contactors, which are interchangeable with many standard IEC auxiliary contact and overload relay accessories.
This Fuji Electric SC-E3/G SE65AG 65A 3-pole magnetic contactor has been inspected and appears to be in good used condition. It was pulled from a working environment where it was previously in service. The unit shows normal wear consistent with industrial use — the housing is intact, the terminal hardware looks clean, and no damage is visible. We have had multiple units of this contactor in stock, and the unit you receive may vary slightly from the one photographed but will be functionally equivalent. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Fuji Electric |
Model: |
SC-E3/G |
MPN: |
SE65AG |
SKU: |
49509 |
Type: |
Magnetic Motor Contactor |
Poles: |
3-Pole |
Continuous Current Rating: |
65A (100A continuous per UL label) |
Coil Voltage: |
24V DC |
Frame Width: |
67mm |
Voltage Rating (AC): |
110–120V / 200–240V / 440–480V / 550–600V |
HP Rating (1-Phase): |
5HP @ 110-120V; 15HP @ 200-240V |
HP Rating (3-Phase): |
20HP @ 200-240V; 25HP @ 440-480V; 50HP @ 550-600V |
Short Circuit Rating: |
5kA, 600V |
Max Fuse: |
K5, RK5 125A |
Max Circuit Breaker: |
125A |
Wire Rating: |
75°C, Copper Wire Only |
UL Listed: |
Yes — IND. CONT. EQ. 253C |
TUV Certified: |
Yes — TUV Rheinland |
CE Marked: |
Yes |
Configuration: |
Non-Reversing |
Coil Terminals: |
A1 / A2 (DC 24V) |
Load Terminals: |
1L1, 3L2, 5L3 (line) / 2T1, 4T2, 6T3 (load) |
Country/Region of Manufacture: |
China |
Form Factor: |
DIN Rail / Panel Mount |
Seller Notes: |
Contactor only — no auxiliary contacts, cables, or mounting accessories included. |
Condition Notes: |
This Fuji Electric SC-E3/G SE65AG 65A 3-pole magnetic contactor has been inspected and is in good used condition. Pulled from a working environment. Housing intact, terminals clean, normal wear. Multiple units in stock; unit may vary from photo. |
