Description
Eaton Advanced Electronics CA-1 1-500783-324 CISPR/ANSI Adapter Instruction Manual 1977
This is the original printed Instruction Manual for the Eaton Advanced Electronics (formerly Singer Instrumentation) CISPR/ANSI Adapter, Model CA-1. Publication number 1-500783-324, this is the 1st Print dated July 1977, covering instruments with Serial No. 101 and above. A 'Manual Changes' stamp on the title page confirms that addendum(s) are included at the rear of the manual.
Specifications & What's Included
- Document type: Instruction Manual
- For instrument: CISPR/ANSI Adapter, Model CA-1
- Publisher/Brand: Eaton Advanced Electronics (originally produced by Singer Instrumentation, Los Angeles, CA)
- Publication number: 1-500783-324
- Print date: 1st Print, July 1977
- Serial number coverage: Serial No. 101 and above
- Format: Printed, comb/spiral-bound
- Language: English
- Addendum(s) included at rear of manual (per title-page stamp)
Applications
The CA-1 CISPR/ANSI Adapter is a specialized instrument used in electromagnetic compatibility (EMC) and electromagnetic interference (EMI) testing. It adapts measurement systems for compliance testing to both CISPR (International Special Committee on Radio Interference) and ANSI (American National Standards Institute) standards — two of the primary regulatory frameworks governing radiated and conducted emissions from electronic equipment. This type of adapter was used in EMC test labs, government compliance facilities, and electronics manufacturers' quality assurance departments during the 1970s and beyond to ensure that products met international and domestic radio interference limits. The CA-1 features a large analog meter movement and attenuator controls, as shown in the manual's Figure 1-L diagram, consistent with quasi-peak and average detector measurement practice common to that era of EMC instrumentation. This manual is an essential reference for technicians operating, calibrating, or servicing a CA-1 unit, particularly those covering Serial No. 101 and above.
This Eaton Advanced Electronics CA-1 CISPR/ANSI Adapter Instruction Manual (pub no. 1-500783-324) has been inspected and is in good used condition. The comb binding is intact and the manual lies flat. Pages appear complete and legible, with normal shelf wear to the covers. A 'Manual Changes — See Addendum(s) at Rear of This Manual' stamp is visible on the title page, indicating addenda are included. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Eaton Advanced Electronics |
Model: |
CA-1 |
MPN: |
1-500783-324 |
Type: |
Instruction Manual |
SKU: |
27809 |
Document Title: |
Instruction Manual for CISPR/ANSI Adapter Model CA-1 |
Publication Number: |
1-500783-324 |
Print Date: |
1st Print 7/77 (July 1977) |
Serial Number Range: |
Serial No. 101 and above |
For Make/Brand: |
Eaton Advanced Electronics / Singer Instrumentation |
For Model: |
CA-1 CISPR/ANSI Adapter |
Document Type: |
Instruction Manual |
Language: |
English |
Format: |
Printed, spiral/comb-bound |
Condition: |
Used – Inspected and in Good Condition |
Seller Notes: |
Includes addendum(s) at rear per front-page stamp |
Condition Notes: |
Eaton CA-1 CISPR/ANSI Adapter Instruction Manual (1-500783-324) inspected and in good used condition. Comb binding intact, pages complete and legible, normal shelf wear. Addendum stamp present on title page. |
