VAT 26344-QA41-0002/0141 Series 26 HV Angle Valve 6-Inch Bellows Sealed
VAT
$1,200.00Was: $2,400.00VAT 26344-QA41-0002/0141 Series 26 HV Angle Valve 6-Inch Bellows SealedThe VAT 26344-QA41-0002/0141 is a Series 26 high vacuum (HV) angle valve with a 6-inch bore, designed for isolation and flow...52221- SKU:
- 52221
- Availability:
- Usually ships within 1-2 business days.
- Weight:
- 41.00 LBS
- Brand:
- VAT
- Model:
- 26344-QA41-0002/0141
- MPN:
- 26344-QA41-0002/0141
- Series:
- Series 26
- Type:
- High Vacuum Angle Valve
- SKU:
- 52221
- Condition:
- Used – Pulled from Working Environment
- Seller Notes:
- Includes pneumatic actuator solenoid valve (N-7510-102 visible on unit)
- Country/Region of Manufacture:
- Switzerland
- Valve Size:
- 6 Inch
- Seal Type:
- Bellows Sealed
- Valve Configuration:
- Angle Valve
- Application:
- High Vacuum (HV)
- Compatible With:
- Semiconductor, research, and vacuum pumping systems
- Actuator Type:
- Pneumatic
- Solenoid Valve PN:
- N-7510-102
- Overall Dimensions:
- 14 x 12 x 9 inches
- Form Factor:
- Inline / Flanged
- Condition Notes:
- VAT 26344-QA41-0002/0141 Series 26 HV angle valve inspected and in good used condition. Pulled from a working environment where it was in active use and functional. Solenoid actuator (N-7510-102) present and intact.
- California Prop 65 Warning:
- WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov
$1,200.00Was: $2,400.00 -
VAT X-VAT100-40496 Air Actuated Valve Port 100mm High Vacuum Chamber SS 56"
VAT
$2,200.00Was: $4,400.00VAT X-VAT100-40496 Air Actuated Valve Port 100mm High Vacuum Chamber SS 56"The VAT X-VAT100-40496 is a pneumatically actuated (air actuated) stainless steel valve port assembly designed for high...52207- SKU:
- 52207
- Availability:
- This item requires freight shipping. Please contact us for a freight quote before ordering.
- Weight:
- 151.00 LBS
- Brand:
- VAT
- Model:
- X-VAT100-40496
- MPN:
- X-VAT100-40496
- Secondary Model:
- 0240X-AA24-CIW1/0002
- Type:
- Air Actuated High Vacuum Valve Port
- Fabrication Number:
- 0240X-AA24-CIW1/0002
- Actuator Reference:
- ZXX 24-100-75
- Bore Diameter:
- 100 mm (Ø 100 mm)
- Stroke:
- 75 mm
- Pressure Range:
- 1 – 10 bar
- Maximum Temperature:
- 80°C (Tmax)
- Actuation Type:
- Pneumatic / Air Actuated
- Body Material:
- Stainless Steel
- Overall Length:
- 56 inches (approx. 142 cm)
- Overall Height:
- 17 inches
- Overall Width:
- 4 inches
- Application:
- High Vacuum Chamber Isolation
- Country/Region of Manufacture:
- Switzerland
- Form Factor:
- Floor-Standing / Rail-Mounted Assembly
- Quantity of Valve Actuators:
- 3
- Shipping Method:
- Freight Required
- Condition:
- Used – Pulled from Working Environment
- SKU:
- 52207
- Seller Notes:
- 3x VAT valve actuators on SS valve cover; freight shipping required
- Condition Notes:
- VAT X-VAT100-40496 vacuum valve assembly inspected, good used condition. Removed from solar panel mfg vacuum chamber. All 3 actuators present. Original crate included. Freight shipping required.
- California Prop 65 Warning:
- WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov
$2,200.00Was: $4,400.00
