Anritsu MP1570A SONET/SDH/PDH/ATM Analyzer Operation Manual Vol.7 2.5G Jitter

Anritsu MP1570A SONET/SDH/PDH/ATM Analyzer Operation Manual Vol.7 2.5G Jitter

This is the original printed Operation Manual for the Anritsu MP1570A SONET/SDH/PDH/ATM Analyzer, Volume 7, First Edition. This volume covers 2.5G Jitter and Wander Measurement, specifically describing the measurement procedures and screen operations that can be performed by installing the MP0130A 2.5G Jitter unit into the MP1570A analyzer.

Specifications & What's Included

• Manufacturer: Anritsu
• For Instrument: MP1570A SONET/SDH/PDH/ATM Analyzer
• Document Type: Operation Manual
• Volume: Vol.7
• Edition: First Edition
• Subject Coverage: 2.5G Jitter/Wander Measurement
• Compatible Module Covered: Anritsu MP0130A 2.5G Jitter Unit
• Language: English
• Format: Printed, bound manual
• Screens Documented: Setup, Test Menu, Result, Analyze (each with subsections per the manual's own description)

Applications

The Anritsu MP1570A is a multi-protocol transport analyzer designed for testing SONET, SDH, PDH, and ATM networks at rates up to 2.5 Gbps (OC-48/STM-16). It is used by telecom engineers and network equipment manufacturers for commissioning, troubleshooting, and compliance testing of synchronous optical and digital transport systems. Volume 7 of the operation manual specifically addresses Jitter and Wander measurement — critical parameters in synchronous networks where accumulated timing deviation can cause bit errors and synchronization failures. This type of manual is essential for operators and technicians configuring the MP0130A jitter measurement option and interpreting the analyzer's Jitter/Wander test screens and results. The MP1570A platform was a widely used reference instrument during the late 1990s and 2000s build-out of SONET/SDH backbone networks, and this manual remains relevant for labs and facilities that continue to maintain or operate this equipment.
