Description
Acopian B25G110 Linear Regulated Power Supply 24VDC 1.1A 120VAC 6/10A Fuse
The Acopian B25G110 is a single-output linear regulated AC/DC power supply manufactured by Acopian Technical Company of Easton, PA. It converts 120VAC mains power to a regulated 24VDC output at up to 1.1 amps, with an adjustable output range of ±1VDC. The unit is housed in a compact ventilated gold-anodized steel chassis with screw-terminal connections for both AC input and DC output.
Specifications & What's Included
- Model: Acopian B25G110
- Type: Linear Regulated AC/DC Power Supply
- Output Voltage: 24 VDC (±1 VDC adjustable)
- Output Current: 1.1 A
- Number of Outputs: 1
- Input Voltage: 120 VAC
- Fuse Rating: 6/10 A, 250V
- Output Terminals: +OUT, −OUT screw terminal block
- Input Terminals: L A.C., N A.C., Ground screw terminal block
- Regulation Type: Linear
- Overall Dimensions: 5.5 × 5 × 3.5 in
- Chassis: Ventilated gold-anodized steel enclosure
- Manufactured by: Acopian Technical Company, Easton, PA, USA
Applications
Acopian linear regulated power supplies are a long-established standard in laboratory, instrumentation, and industrial electronics applications. Unlike switching supplies, linear regulators produce exceptionally low output noise and ripple, making them well suited for powering sensitive analog instrumentation, measurement equipment, signal conditioning circuits, and any application where clean, stable DC voltage is critical. The B25G110's 24VDC output is a common rail voltage for industrial sensors, PLCs, relay logic, and process control instrumentation. Acopian has been producing this style of chassis-mount linear supply since the 1960s and 1970s, and the B-series format — a self-contained metal enclosure with screw terminals — has remained in continuous production and use across decades of industrial and lab environments. These supplies are commonly found on lab benches, in equipment racks, and wired into instrument panels wherever a reliable, low-noise 24V source is needed.
This Acopian B25G110 Linear Regulated AC/DC Power Supply has been inspected and is in good condition. The gold-anodized chassis shows light surface wear consistent with normal use, and an inspection acceptance sticker is visible on the unit. The terminal block and fuse holder appear intact. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Acopian |
Model: |
B25G110 |
MPN: |
B25G110 |
Type: |
Linear Regulated AC/DC Power Supply |
SKU: |
48760 |
Output Voltage: |
24 VDC (±1 VDC Adjustable) |
Output Current: |
1.1 A |
Input Voltage: |
120 VAC |
Number of Outputs: |
1 |
Fuse Rating: |
6/10 A, 250V |
Regulation Type: |
Linear |
Form Factor: |
Benchtop / Open Frame Chassis |
Dimensions: |
5.5 x 5 x 3.5 in |
Output Terminals: |
+ OUT, − OUT screw terminal block |
Input Terminals: |
L A.C., N A.C., Ground screw terminal block |
Country/Region of Manufacture: |
United States |
Seller Notes: |
Unit only — no accessories. Inspected and in good condition. |
Condition Notes: |
Acopian B25G110 Linear Regulated Power Supply, 24VDC 1.1A. Inspected and in good condition. Light surface wear consistent with normal use. Terminal block and fuse holder intact. |
