The Zilog Z80BCPU (part number Z8400BB1) is a B-speed-grade variant of the classic Zilog Z80 8-bit microprocessor, manufactured here by SGS-Thomson (marked "ST" on the chip body). The Z80B runs at up to 6 MHz and is housed in a standard 40-pin DIP package, making it a direct drop-in replacement in any Z80-compatible socket. Price is for one (1) chip.

Specifications & What's Included

• Manufacturer: SGS-Thomson (ST) — licensed Zilog Z80 production
• Part Number: Z8400BB1
• Device Designation: Z80BCPU
• Architecture: 8-bit CMOS/NMOS-compatible
• Speed Grade: B — up to 6 MHz operation
• Package: 40-pin DIP (Dual Inline Package)
• Pin pitch: 0.1" (2.54 mm) standard DIP spacing
• Date codes visible in photos: 28932 (chip 1), 3100 (chip 2)
• Quantity: one (1) CPU chip per purchase

Applications

The Zilog Z80 is one of the most widely used 8-bit microprocessors ever produced, introduced by Zilog in 1976 and subsequently manufactured under license by SGS-Thomson, NEC, Sharp, and other foundries through the 1980s and into the 1990s. It was the central processor in a broad range of personal computers — including the Sinclair ZX Spectrum, Amstrad CPC, TRS-80, MSX platform, and the CP/M ecosystem of business machines — as well as countless embedded control, industrial, and consumer electronics designs. The Z80 also powered a large number of arcade game PCBs and electronic musical instruments of the era. The B-grade (Z80B) variant runs at 6 MHz, offering a modest speed increase over the standard 4 MHz Z80A, and was popular in later S-100 bus and CP/M systems seeking improved throughput. The Z80 remains in production today in CMOS form and continues to see active use in embedded applications, hobbyist retrocomputing, and legacy industrial equipment that cannot easily be re-architected to a modern processor. This SGS-Thomson-made chip is a period-correct replacement for any Z80B socket in vintage computer, arcade, or industrial control hardware.
