Toshiba Dynadock V PA3778U-1PRP USB 2.0 Docking Station DVI Ethernet Headphone

Toshiba Dynadock V PA3778U-1PRP USB 2.0 Docking Station DVI Ethernet Headphone

The Toshiba Dynadock V (PA3778U-1PRP) is a universal USB 2.0 docking station that expands any laptop or desktop into a full desktop workstation through a single USB cable connection. It adds DVI video output, wired Gigabit Ethernet, three USB 2.0 ports, and headphone and microphone jacks — no proprietary docking connector required.

Specifications & What's Included

• Model: PA3778U-1PRP (Dynadock V)
• Host connection: USB 2.0 (Type B upstream port)
• Video output: DVI-I port
• USB 2.0 ports: 3 total — 2 on rear panel, 1 powered port on side panel (supports USB Sleep & Charge)
• Network: RJ-45 Gigabit Ethernet port
• Audio: 3.5mm headphone jack and 3.5mm microphone jack (side panel)
• Security: Kensington lock slot
• Form factor: Vertical desktop stand
• Country of manufacture: China
• Included accessories:
• Toshiba Dynadock V dock unit on vertical stand
• AC adapter with power cord
• USB Type A-to-B connection cable
• DVI-to-VGA adapter
• Dynadock V Installation CD — Software Version 2.5.0.5 (driver, utility, and User's Manual)
• Printed Quick Start guide
• Original retail box

Applications

The Dynadock V belongs to Toshiba's line of USB-based universal docking stations, designed for laptop users who want a quick and cable-free way to connect to a full suite of desktop peripherals. Because it connects via standard USB 2.0 rather than a proprietary port, it works with virtually any Windows laptop or desktop with a USB port — not just Toshiba machines. A typical setup uses the single USB cable to simultaneously drive an external DVI monitor (or VGA monitor via the included adapter), a wired Ethernet network connection, external speakers or headphones, a microphone, and additional USB peripherals. The powered side USB port supports Toshiba's USB Sleep & Charge feature, which keeps charging connected devices even when the host computer is in sleep mode. These USB docking stations were a practical solution in the late 2000s and early 2010s for users who moved frequently between desk and mobile work, and units like the Dynadock V remain useful today for older Windows systems that lack built-in DisplayPort or USB-C docking support.
