Tektronix VX4372 2-Wire Relay Scanner Slave Module Operating Manual

Tektronix VX4372 2-Wire Relay Scanner Slave Module Operating Manual

This is the original printed operating manual for the Tektronix VX4372 2-Wire Relay Scanner Slave Module, a VXIbus-format switching module used in automated test and measurement systems. The manual is published by Tektronix and presented in a standard Tektronix ring binder. It covers the full scope of information needed to install, configure, and operate the VX4372 in a VXI-based test system.

Specifications & What's Included

• Manufacturer: Tektronix
• Model: VX4372
• Full title: VX4372 2-Wire Relay Scanner Slave Module Operating Manual
• Format: Printed manual in Tektronix ring binder
• Language: English
• Platform / bus: VXIbus
• Contents per Table of Contents: Section 1 – General Information and Specifications (controls and indicators, LEDs, fuses, front panel connectors, VXIbus compatibility, specifications); Section 2 – Preparation for Use (installation requirements and cautions, installation procedure, installation checklist); Section 3 – Operation; Section 4 – Programming Examples; Appendix A – Input/Output Connections
• List of Illustrations includes: VX4372 Front Panel, Controls and Indicators, Module Installation, Cabling Examples, Jumpers and Optional Resistors

Applications

The Tektronix VX4372 is a 2-wire relay scanner slave module designed for use in VXIbus automated test systems. It expands switching capacity within a VXI mainframe by operating as a slave to a master scanner module, allowing large-scale signal routing and multiplexing across a device under test. This type of relay scanner module was used in semiconductor test, electronic manufacturing test, and general-purpose automated test equipment (ATE) setups where many signal lines must be systematically switched and measured. The VXIbus standard, which gained wide adoption in the late 1980s and through the 1990s, combined IEEE 488 (GPIB) instrument control concepts with a high-speed VMEbus-based backplane, enabling modular, rack-integrated test systems with tight instrument synchronization. This manual is the reference needed by engineers maintaining or programming legacy VXI-based test systems that include the VX4372.
