Tektronix 1230 Logic Analyzer 16-Channel w/ P6444 Probe Leads & Reference Guide
The Tektronix 1230 is a 16-channel benchtop logic analyzer designed for digital circuit debugging, timing analysis, and state analysis. It features a built-in CRT display, a dedicated front-panel keypad for direct menu-driven operation, and dual probe bays (Probe A and Probe B) for connecting the P6444 pod and compatible probes. This unit runs firmware V4.02 and is from Tektronix's late-1980s logic analyzer line.
Specifications & What's Included
- Manufacturer: Tektronix
- Model: 1230 (1230/16)
- Type: 16-Channel Logic Analyzer
- Display: Built-in CRT monitor
- Firmware: V4.02 (Tektronix, 1988–1989)
- Front panel: Full keypad with labeled function keys — DON'T CARE, MENU, NOTES, ENTER, navigation arrows, POWER indicator (green LED)
- Probe inputs: Probe A and Probe B connector bays on front panel
- Rear panel: 4 expansion slots, External Clock In (BNC), red power on/off switch, IEC AC power inlet
- Form factor: Benchtop / portable with integrated carry handle/stand
- Included: Tektronix P6444 probe module
- Included: Test leads and micro-clip set (in bag)
- Included: Probe tip adapters (gold-pin style, 3 sets)
- Included: Tektronix 1230 Reference Guide (printed booklet)
- Soft carry/dust cover included
Applications
The Tektronix 1230 belongs to a class of standalone benchtop logic analyzers that were standard tools in digital electronics labs and engineering departments from the mid-1980s through the mid-1990s. Logic analyzers capture and display multiple digital signals simultaneously, making them essential for debugging timing relationships, verifying bus protocols, and tracing logic states in microprocessor-based and digital circuit designs. The 1230 was aimed at engineers working on embedded systems, board-level digital design, and microcomputer development — environments where an oscilloscope alone couldn't capture the multi-channel, high-speed digital events that needed to be sorted out. With its self-contained CRT, keypad, and probe system, it was designed to operate as a standalone instrument without a PC host, which was the dominant architecture for logic analyzers of that era. Today the 1230 continues to find use in vintage computer restoration, legacy system maintenance, and educational settings where its hands-on, dedicated-hardware approach suits the work well.
This Tektronix 1230 16-Channel Logic Analyzer has been inspected and photographed as shown. The photos show the unit powered on with the startup screen displayed and the green POWER LED lit — the display comes up and shows firmware V4.02. The front panel keypad, CRT display, and probe connector bays all appear intact and in good shape. The rear panel slot covers show some yellowing typical of equipment from this era, and there is light cosmetic wear on the chassis consistent with age and normal use — nothing that affects function. The unit comes with the P6444 probe module, a set of test leads and micro-clips, probe tip adapters, and the Tektronix 1230 Reference Guide. It was not bench-tested by our staff beyond visual inspection and the powered-on photos — please review all photos carefully and contact us with any questions before purchasing.
