Description
Sun Microsystems CP2060-500 Netra CP2060 cPCI 6U System Controller Board
The Sun Microsystems CP2060-500 is a 6U CompactPCI (cPCI) system controller board designed for the Sun Netra CP2060 platform. It integrates an UltraSPARC IIe 500 MHz processor with onboard IPMI-based system management and environmental monitoring, making it a full-featured single-board computer and chassis controller in a single cPCI blade form factor. The board supports hot swap in high-availability (HA) configurations and connects via J1, J2, J3, and J5 backplane slots.
Specifications & What's Included
- Model: Sun Microsystems CP2060-500
- Platform: Sun Netra CP2060
- Processor: UltraSPARC IIe, 500 MHz
- Memory: 256 MB or 512 MB RAM (configuration dependent)
- Form Factor: 6U CompactPCI (cPCI)
- Bus Interface: CompactPCI (cPCI)
- Backplane Connections: J1, J2, J3, J5
- System Management: IPMI with environmental monitoring
- High Availability: HA Hot Swap support
- Front Panel: ABORT, RESET, ALARM/USER, and READY status LEDs; Sun Microsystems logo and model label
- Front Panel Ejector Handles: Red locking ejectors (top and bottom)
- Assembly: 3021-04 REV 53, Assembled in Canada – Toronto
- Included: Board only (no enclosure, cables, or accessories)
Applications
The Sun Netra CP2060 platform was Sun Microsystems' carrier-grade CompactPCI solution, designed for telecommunications and network infrastructure applications requiring high availability and fault tolerance. The CP2060-500 system controller board served as the central processing and management blade within a Netra cPCI chassis, running Solaris and managing system health through IPMI. This class of equipment was commonly deployed in telecom central offices, network operations centers, and data centers that demanded continuous uptime and hot-swap serviceability. The Netra line was Sun's answer to NEBS-compliant, carrier-grade computing in the late 1990s and early 2000s, and systems built on this platform remain in service in legacy telecom and industrial control environments where Solaris-based cPCI infrastructure has not been replaced. Replacement blades like this one are sought by operators maintaining existing Netra chassis and by integrators sourcing spare controller boards for those systems.
This Sun Microsystems CP2060-500 Netra CP2060 cPCI 6U System Controller Board has been inspected and is in good used condition. It was pulled from a working Sun Netra cPCI enclosure where it was in active use. The board shows normal light wear consistent with service use; the faceplate, status LEDs, and ejector handles are intact and appear undamaged. The PCB, memory slots, and backplane connectors are clean with no visible corrosion or physical damage. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
Sun Microsystems |
Model: |
CP2060-500 |
MPN: |
CP2060-500 |
Secondary Model: |
Netra CP2060 |
Type: |
cPCI System Controller Board |
SKU: |
24165 |
Processor: |
UltraSPARC IIe 500 MHz |
Memory: |
256 MB or 512 MB RAM (configuration dependent) |
Form Factor: |
6U CompactPCI (cPCI) |
Bus Interface: |
CompactPCI (cPCI) |
Connector Compatibility: |
J1, J2, J3, J5 |
Management: |
IPMI System Management and Environmental Monitoring |
High Availability: |
HA Hot Swap Support |
Condition: |
Used – Pulled from Working Environment |
Country/Region of Manufacture: |
Canada |
Compatible With: |
Sun Netra CP2060 cPCI Enclosure / Chassis |
Seller Notes: |
Board only; pulled from a working Sun Netra cPCI enclosure. |
Condition Notes: |
Sun CP2060-500 Netra CP2060 cPCI 6U System Controller Board. Inspected and in good used condition. Pulled from a working Sun Netra cPCI enclosure. Board, LEDs, and connectors appear undamaged. |
