SMC NVZ2150-5MZ Solenoid Valve 24V VZ2150 1-9.9 kgf/cm² A16-316 w/ Gasket

SMC NVZ2150-5MZ Solenoid Valve 24V VZ2150 1-9.9 kgf/cm² A16-316 w/ Gasket

The SMC NVZ2150-5MZ is a 5-port directional control solenoid valve from SMC's VZ2150 series, rated for 24V DC operation and a working pressure range of 1 to 9.9 kgf/cm². This is a double-solenoid (EAPEB) configuration valve designed for pneumatic directional control in automated machinery and process equipment. It features a compact aluminum body with an integrated solenoid actuator block and pre-wired lead connections, and is designed for manifold or sub-base mounting within SMC VZ2000 series systems.

Specifications & What's Included

• Brand: SMC Corporation
• Model: NVZ2150-5MZ
• Series: VZ2150
• Lot / Order Code: A16-316
• Valve Type: 5-Port Directional Control Solenoid Valve
• Solenoid Configuration: EAPEB (Double Solenoid)
• Coil Voltage: 24V DC
• Working Pressure Range: 1 to 9.9 kgf/cm²
• Port Configuration: A, B (as labeled on valve body)
• Wiring: Pre-wired red and black lead wires with connector block
• Mounting: Manifold / sub-base mount (VZ2000 series compatible)
• Country of Manufacture: Japan
• Includes: Gasket

Applications

SMC VZ2150 series solenoid valves are used in pneumatic automation systems to control the direction of compressed air flow to actuators such as cylinders and rotary drives. They are common in manufacturing, semiconductor fabrication, packaging machinery, robotics, and general industrial automation where precise, electrically controlled directional switching of air pressure is required. The 5-port design allows for control of double-acting cylinders — directing air to one side of a piston while exhausting the other — making them a standard building block in automated production lines and motion control systems. SMC is a Japanese manufacturer and one of the largest pneumatics suppliers globally; VZ series valves are widely used across industries and have replacement parts and sub-bases readily available.
