SMC AR30-N03-Z Air Pressure Regulator 7-125 PSI 3/8 NPT with Gauge
The SMC AR30-N03-Z is a general-purpose compressed air pressure regulator from SMC's AR series. It reduces and maintains a stable downstream pressure from a higher-pressure compressed air supply, using a top-mounted adjustment knob to set the desired output pressure. An attached SMC analog gauge displays output pressure in both PSI and MPa.
Specifications & What's Included
- Model: AR30-N03-Z
- Manufacturer: SMC Corporation
- Type: Air pressure regulator (pressure-reducing)
- Set pressure range: 7 ~ 125 PSI
- Port size: 3/8 NPT (IN port 1, OUT port 2)
- Port configuration: IN and OUT labeled on body casting
- Adjustment: Top-mounted rotary knob
- Body material: Zinc die-cast metal
- Included: SMC analog pressure gauge, dual-scale 0–160 PSI / 0–1.1 MPa, RoHS-marked
- Media: Compressed air
- Country of manufacture: China
- Series: SMC AR Series
Applications
The SMC AR series regulators are widely used in industrial pneumatic systems to supply clean, regulated air at a consistent pressure to downstream equipment such as pneumatic cylinders, actuators, air tools, and process instrumentation. The AR30 size is suited for medium-flow applications in manufacturing, assembly automation, and machine tool environments. The 3/8 NPT porting is standard for mid-range pneumatic circuits, and the integrated gauge provides at-a-glance pressure confirmation without a separate gauge port. SMC is one of the most widely specified pneumatic component brands in industrial automation globally, and AR-series regulators are common in production machinery across a wide range of industries.
This SMC AR30-N03-Z air pressure regulator has been inspected and is in good used condition. The body and adjustment knob show light surface wear consistent with prior industrial use, and there is some patina on the brass elbow fitting at the gauge port. The NPT port threads appear clean and undamaged, as shown in the close-up photo. The included SMC pressure gauge is intact and readable. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
SMC |
Model: |
AR30-N03-Z |
MPN: |
AR30-N03-Z |
Type: |
Air Pressure Regulator |
SKU: |
47000 |
Set Pressure Range: |
7 ~ 125 PSI |
Port Size: |
3/8 NPT |
Port Configuration: |
IN (port 1), OUT (port 2) |
Gauge Included: |
Yes — SMC analog gauge, 0–160 PSI / 0–1.1 MPa |
Gauge Scale: |
0–160 PSI / 0–1.1 MPa |
Media: |
Compressed Air |
Series: |
AR Series |
Adjustment Type: |
Knob (top-mounted, non-relieving) |
Body Material: |
Metal (zinc die-cast) |
Country/Region of Manufacture: |
China |
Seller Notes: |
Includes attached SMC analog pressure gauge. No additional accessories. |
Condition Notes: |
SMC AR30-N03-Z air pressure regulator inspected and in good used condition. Light surface wear on body; brass gauge elbow shows patina. NPT threads clean. SMC pressure gauge included and intact. |
