SMC AR2000-02 Modular Pneumatic Pressure Regulator 0.05-0.85 MPa 1/4" NPT

SMC AR2000-02 Modular Pneumatic Pressure Regulator 0.05-0.85 MPa 1/4" NPT

The SMC AR2000-02 is a modular-type pneumatic pressure regulator from SMC Corporation's AR series, designed to regulate downstream air pressure within compressed-air systems. It features a 1/4" female NPT port and an adjustment range of 0.05 to 0.85 MPa, making it suitable for a wide range of pneumatic control applications. The compact modular body is compatible with SMC's FRL (Filter-Regulator-Lubricator) modular assembly systems and can be used as a standalone inline regulator or ganged with other AR-series components.

Specifications & What's Included

• Model: SMC AR2000-02
• Type: Modular Pneumatic Pressure Regulator
• Set Pressure Range: 0.05 to 0.85 MPa
• Port Size: 1/4" FNPT (female NPT)
• Configuration: Modular (AR series)
• Body Material: Aluminum valve body with black plastic adjustment knob
• Adjustment: Manual knob with lockable adjustment
• Push-in tube fittings visible on inlet and outlet ports
• Country of Manufacture: Japan
• Regulator unit only — no mounting brackets or additional accessories

Applications

The SMC AR2000 series is a widely used modular pneumatic regulator found throughout industrial automation, machine building, and process equipment. These regulators are standard components in pneumatic FRL assemblies, where they maintain consistent downstream air pressure to actuators, cylinders, valves, and tooling regardless of upstream supply fluctuations. The AR2000-02's 1/4" NPT port size suits light-to-medium duty pneumatic circuits commonly found on assembly lines, robotic end-effectors, packaging machinery, and semiconductor fab equipment. SMC is one of the world's largest pneumatics manufacturers, and AR-series regulators are used globally across virtually every industry that relies on compressed air.
