Skynet Electronic SNP-192 Switching Power Supply 192W 115V 230V Dual Voltage

(No reviews yet) Write a Review
SKU:
52904
MPN:
SNP-192
Condition:
Used
Availability:
Usually ships within 1–2 business days.
Weight:
8.00 LBS
Shipping:
Calculated at Checkout
  • Skynet Electronic SNP-192 192W switching power supply – front and top view showing steel chassis, yellow caution label, and output wiring harness
  • Skynet Electronic SNP-192 specification label showing AC input 115V/5A or 230V/2.5A and DC output rails +5V/20A +12V/7.3A -12V/0.3A -5V/0.3A with CSA and UL markings
  • SNP-192 panel-mount rocker power switch – close-up showing On/Off positions on black housing mounted to steel chassis
  • Skynet SNP-192 output wiring harness – Molex 4-pin and auxiliary connectors on multi-conductor cable bundle
  • Skynet Electronic SNP-192 switching power supply – angled side view showing ventilation slots and output harness routing
  • Skynet Electronic SNP-192 rear view showing IEC AC inlet, rear exhaust fan with guard, and rocker switch panel
$125.00
Was: $225.00
Current Stock: 1

Sold Out

Description

Skynet Electronic SNP-192 Switching Power Supply 192W 115V 230V Dual Voltage

Open-frame switching power supply rated for 192W output. Accepts dual input voltage (115V or 230V) and delivers regulated DC power across four output rails. Unit includes hardwired output harness with Molex 4-pin connector.

Specifications & What's Included

  • Model: SNP-192 | Power Rating: 192W
  • AC Input: 115V~/5A or 230V~/2.5A, 50/60Hz
  • DC Outputs: +5V/20A, +12V/7.3A, -12V/0.3A, -5V/0.3A
  • Connector: Molex 4-pin hardwired harness
  • Form Factor: Open frame, steel chassis with rear-exhaust fan
  • Certifications: UL (E104272), CSA (LR57450)
  • Includes: Unit with attached output harness only

Applications

Switching power supplies of this type are used in industrial control systems, telecommunications equipment, networking devices, and legacy computer systems. The dual-voltage input design accommodates both North American and international power standards. Commonly found in server racks, PBX systems, and industrial automation equipment from the 1990s–2000s era.

Please note: We may have multiple units of this item in stock. The unit you receive may vary slightly from the one shown in the photos. All units are functionally equivalent and inspected to the same standard.

Condition: Used
Skynet Electronic SNP-192 192W switching power supply in used condition. This unit was pulled from a working environment and has been tested and verified to power on and function. The steel chassis exhibits light surface wear and minor scuffing on the top and side panels consistent with normal service use. Output wiring harness, Molex connectors, rear exhaust fan, IEC AC inlet, and panel-mount rocker switch are all intact and in good working condition. Specification label is fully legible. Dual voltage capability (115V/230V) intact and ready for use.
View AllClose

Warranty Information

We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose

Additional Information

Brand:
Skynet Electronic
Model:
SNP-192
MPN:
SNP-192
SKU:
52904
Condition:
Used – Pulled from Working Environment
Seller Notes:
Unit only; no accessories included. Output harnesses attached.
Form Factor:
Open Frame / Steel Chassis
Power Output:
192W
AC Input Voltage:
115V~/5A or 230V~/2.5A, 60/50Hz
DC Output - Rail 1:
+5V / 20A
DC Output - Rail 2:
+12V / 7.3A
DC Output - Rail 3:
-12V / 0.3A
DC Output - Rail 4:
-5V / 0.3A
Frequency:
50/60 Hz
Certifications:
UL (E104272), CSA (LR57450)
Connector Type:
Molex 4-pin (hardwired harness)
Power Switch:
Panel-mount rocker On/Off switch
Cooling:
Internal fan (rear-exhaust)
Country of Manufacture:
Taiwan
Condition Notes:
Tested & working. Light cosmetic wear on chassis. Dual voltage (115V/230V) switching power supply. All connectors, fan, and controls intact and functional.
View AllClose

Related Products

Related Products

Power Tronics SK-4145DE 145W AT switching power supply — angled front view showing fan, IEC inlet, and output harness Power Tronics SK-4145DE label showing switching power supply specs: 115V/230V input, DC output ratings, UL/CSA/TUV certifications
Add to Cart
Quick view

Power Tronics SK-4145DE 145W AT Switching Power Supply 115V/230V w/ Switch

Power Tronics

$70.00
Was: $150.00
Power Tronics SK-4145DE 145W AT Switching Power Supply 115V/230V w/ Switch AT form factor switching power supply rated for 145 watts. Provides regulated DC output for legacy desktop computer systems...
19133
SKU:
19133
Availability:
Usually ships within 1-2 business days.
Weight:
5.00 LBS
Brand:
Power Tronics
Model:
SK-4145DE
MPN:
SK-4145DE
SKU:
19133
Condition:
Used – Inspected and Tested
Seller Notes:
Includes power cord and external power switch with harness
Form Factor:
AT Desktop
Power Output:
145 Watts
Input Voltage:
115V/230V AC (selectable on metal case)
Input Current:
4A at 115V / 2A at 230V
Frequency:
60/50 Hz
DC Output +5V:
+5V: 1.5A min, 14A max
DC Output +12V:
+12V: 0A min, 6A max
DC Output -5V:
-5V: 0A min, 0.3A max
DC Output -12V:
-12V: 0A min, 0.3A max
Power Supply Type:
Switching Power Supply
Connector Standard:
AT (P8/P9 motherboard connector)
Certifications:
UL (E 134129), CSA (LR 804), TUV Rheinland
Standards:
IEC Publication 950
Compatible With:
AT form factor desktop computers
Country of Manufacture:
Taiwan
Condition Notes:
Power Tronics SK-4145DE 145W AT Switching Power Supply. Tested and in good working order. Includes power cord and external switch. Normal cosmetic wear. Please contact us with any questions.
Han One HN-0150SB IBM AT XT style power supply – left-side angle view showing black enclosure and external red flip ON/OFF switch Han One HN-0150SB power supply – rear view showing IEC AC inlet, cooling fan, and AT-style Molex output harness
